2N VoiceBlue Next v3.0 - Manual (Page 77)

Available Status Messages 4.5
77
4.5 Available Status Messages
The following list of statuses is universal and some messages may not be included in
2N
® VoiceBlue Next.
GSM Layer Statuses
GSM Layer 2
Name Description What Follows
INIT GSM module initialisation start PINREQ
SIM0 Module switch to internal SIM card INIT
PINREQ Module PIN request PINSET
PINSET PIN value sending to module INFO
BLOCK Module blocked temporarily or permanently (see Layer 2 information) INIT
SET-UP Module configuration running IDLE
SLEEP Module sleep running (transition to BLOCK status) BLOCK
NWAIT Awaiting GSM log-in SET-UP
IDLE Rest status, can start/receive call, execute AT&G command CALL/CMD
CALL Call running (call establishing, connected call, call end) IDLE
CMD Communicating with module upon AT&G command IDLE
INFO Information loading from module and SIM card NWAIT
GSM Layer 2 Info for BLOCK
Name Description
(block) Blocked by AT&G command, terminated by module, board or system reset
Netw-reg GSM log-in refused (not activated SIM), next attempt in 5..60 minutes
Clir-err CLIR activation request refused, next attempt in 2..10 minutes
Mod-err Defective or unconnected GSM module, next attempt in 2 minutes
Pin-err Wrong PIN, permanently in BLOCK status
Sim-err Defective or non- inserted SIM card, next attempt in 2 minutes
Log-out Temporarily logged-out according to parameter X00
Puk-req SIM card requires PUK
(undef) This position of SIM card was not checked by gateway
GSM Layer 3
Name Description
NULL Rest status, ready for call
CINIT Request of call to GSM (from Layer 4)
OPROC Call to GSM is connected
CDELIV Call to GSM is ringing
