Web Configuration Interface 3.4
60
o Report to PC + voice message – the GSM gateway sends information on
incoming calls to a PC equipped with the call routing software. The
DTMF dial-in with a voice welcome note can be activated for incoming
calls.
o Report to PC + dialtone – the GSM gateway sends information on
incoming calls to a PC equipped with the call routing software. The
DTMF dial-in with a simulated secondary dialtone can be activated for
incoming calls.
 Minimum digits in DTMF – set the minimum count of digits to be required by
the gateway for DTMF dial-in.
 Maximum digits in DTMF - set the minimum count of digits to be accepted by
the gateway for DTMF dial-in.
 DTMF dialling timeout [s] – set the time for the GSM gateway to wait for the
first / next DTMF digits. If you set this parameter to 0, the incoming call is
automatically connected to the numbers included in the List of called
numbers.
 Day of deleting GSM incl. group statistics - define a day in a month on which
the statistics on incoming calls should be deleted.
 Prefix before DISA dial-in – enter a numerical prefix to be automatically
inserted before the DTMF dial-in.
 CLIP – use this parameter to modify the CLIP from GSM/UMTS networks. „+‟
is removed automatically from international identifiers. Use „-‟ to remove a
digit. Examples (GSM
CLIP +420600123456) :
Parameter CLIP to
VoIP/PRI 1 Note
Null 420261301500 No CLIP change
+ +420261301500 + inserted before CLIP received
00 00420261301500 00 inserted before CLIP received
-- 0261301500 First two digits removed from CLIP received
---99 99261301500 First three digits removed from CLIP received,
prefix „99‟ added
 Looping of voice message – set the voice message playing time.
Send CLIP from GSM/UMTS to VoIP
 Transfer CLIP from GSM/UMTS – enable/disable the function.
 Separating char – enter the character to separate the calling SIM card CLIP
and ID extension to be called.
 Modify – modify the ID extension.
Caution
 The Send CLIP from VoIP to GSM service must be supported by the
GSM/UMTS provider. If not, not, the provider‟s network may reject the
call!
