SECTION 4 - PLATFORM
96
1930ES,2030ES,2630ES,2646ES,3246ES,PRIOR TO SN 0200135154
3121246
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Except CE and 1 for CE Specs. Use decal required for
applicable spec. Dispose of the decal not used.
1001091965
1
Kit 3 - Decal, Housing and PC Board Kit (Includes Items 2, 6,
12, 16 & 19)
A
Ref
Note: Two Item 6's are included in the kit - 1 for All Specs
Except CE and 1 for CE Specs. Use decal required for
applicable spec. Dispose of the decal not used.
0272878
Ref
ANTI-VANDELISM PACKAGE INSTALLATION (NOT SHOWN)
A
1671131
1
Cover, Lockable Platform Console Box
1001118216
Ref
PLATFORM BOX COVER INSTALLATION (was p/n 0273841)
A-C
101
1001118215
Kit, Platform Box Shield (was p/n 2902341)
101A
0760808
4
Bolt M8 x 16mm
101B
1380159
4
Clip, Cover Mounting
101C
1001116154
1
Cover, Platform Box (was p/n 1671161)
101D
3290805
4
Locknut M8
0274386
Ref
PLATFORM BOX HANGER INSTALLATION (OPTIONAL)
B
201
3290405
2
Locknut M4
202
3575794
1
Plate, Bracket
203
3900338
2
Screw M4 x 20mm
204
4811400
4
Flatwasher M4
