Page 49
SECTION 2 - GROUND COMPONENTS
3121246
1930ES,2030ES,2630ES,2646ES,3246ES,PRIOR TO SN 0200135154
49
FIGURE 2-3. GROUND CONTROL ASSEMBLY AND INSTALLATION (USA BUILT MACHINES AND
BELGIUM BUILT MACHINES) (Prior to SN 0200117805, Prior to SN 1200001367)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
GROUND CONTROL ASSEMBLY (USA BUILT MACHINES)
(Prior to SN 0200117805)
Ref
GROUND CONTROL ASSEMBLY (BELGIUM BUILT MACHINES)
(Prior to SN 1200001367)
0272780
Ref
ANSI and ANSI Export Specs
I
0273444
Ref
Australian Spec
F
0272781
Ref
CE Spec
I
1
0380025
1
Box, Ground Control
2
0610161
1
Board, PC (Battery Charger LED)
3
1600419
1
Board, PC (Ground Control) (was p/n 0610164)
Ref
Note: PC Board must be recalibrated when replaced.
3
2915039
1
Upgrade Kit (Includes Cables, Programming Instructions and CD
Software) (Note: Use with p/n 1600419 PC Board. Must be
Purchased Separately.)
B
4
1671105
1
Cover, Front
5
Ref
Decal - LED Options:
5
1705696
1
Decal - LED ANSI/ANSI Export/Australian Spec
5
1705697
1
Decal - LED CE/Australian Spec
6
1705698
1
Decal - Function
7
2420172
1
Hourmeter
8
Ref
Component Options:
8
3520193
1
Plug (ANSI/ANSI Export/Australian Specs)
8
2920026
1
Lamp (CE Spec)
9
Ref
Bulb Options:
9
Not Required
0
Bulb ANSI/ANSI Export Spec
9
2920094
1
Bulb CE/Australian Spec
10
3574330
1
Plate, Mounting
11
3900336
4
Screw, Torx #10-32NC x 1/2in
12
3900337
Screw, Torx M3.5 x 25mm
13
3900338
6
Screw, Torx M4 x 20mm
14
3900339
5
Screw, Plastite #6 x 1/2in
15
4360069
1
Breaker, Circuit - 10 Amp
16
4360328
1
Switch, Toggle
17
Ref
Keyswitch Options:
17
4360469
1
Keyswitch ANSI/ANSI Export Spec
17
4360470
1
Keyswitch CE/Australian Spec
17
2860030
1
Key, Replacement (Fits All Specs)
18
4360475
1
Switch, Emergency Stop
18
7020175
1
Cap
18
7020176
1
Block, Contact
19
2915009
1
Module, Tilt (was P/N 4360535)
20
4922865
1
Harness, Control Box (See ELECTRICAL SECTION for
Breakdown)
21
4922866
1
Harness, Tilt Sensor (See ELECTRICAL SECTION for
Breakdown)
22
4061061
1
Shield
23
4191303
3
Screw M3.5 x 6mm
Ref
GROUND CONTROL BOX INSTALLATION
0272810
Ref
ANSI and ANSI Export Specs
F
0273443
Ref
Australian Spec
D
