SECTION 2 - GROUND COMPONENTS
46 1930ES,2030ES,2630ES,2646ES,3246ES,PRIOR TO SN 0200135154 3121246
ITEM PART NUMBER QTY DESCRIPTION REV
17A 2940175 4 Locking
17A 7027863 4 Key
17B 4071102 4 Shim, Latch (2 Per Cover)
17C 1671203 1 Cover, Battery (USA Built Machines) (SN 0200130607
through 0200135154)
17C 1671203 1 Cover, Battery (Belgium Built Machines) (SN 1200003527
through 1200004293)
17D 1705754 1 Decal - JLG (USA Built Machines) (SN 0200130607 through
0200135154)
17D 1705754 1 Decal - JLG (Belgium Built Machines) (SN 1200003527
through 1200004293)
17E 1706350 2 Decal - Cover (USA Built Machines) (SN 0200130607
through 0200135154)
17E 1706350 2 Decal - Cover (Belgium Built Machines) (SN 1200003527
through 1200004293)
19 4240172 4 Strap, Battery (UL Spec)
Ref TRAY ASSEMBLY OPTIONS:
0273698 Ref USA and Belgium E
0861678 Ref UL Spec C
101 Purchase Item 16 1 Tray, Battery
102 3290605 2 Locknut
103 3340975 2 Pad, Wear (Note: Wear Pad not available separately from Tray
Assembly on some applications.)
104 Ref Stop, Battery Box Options:
Ref NOTE: Requires (2) 3820032 Rivet & (1) 4811600 Washer
104 4220252 1 LH (was p/n 4220208)
104 4220253 1 RH (was p/n 4220208)
105 3820032 AR Rivet (USA Built Machines - Not Shown) (SN 0200130607
through 0200135154)
105 3820032 AR Rivet (Belgium Built Machines - Not Shown) (SN 1200003527
through 1200004293)
106 4811600 AR Washer (USA Built Machines - Not Shown) (SN 0200130607
through 0200135154)
106 4811600 AR Washer (Belgium Built Machines - Not Shown) (SN 1200003527
through 1200004293)
