SECTION 2 - GROUND COMPONENTS
42
1930ES,2030ES,2630ES,2646ES,3246ES,PRIOR TO SN 0200135154
3121246
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
0273110
Ref
Belgium Built Machines (Prior to SN 1200001241)
D
0273698
Ref
USA Built Machines (SN 0200116600 through 0200128413)
D
0273698
Ref
Belgium Built Machines (SN 1200001241 through 1200002974)
D
101
0100011
AR
Compound, Locking
102
0700616
2
Bolt M6 x 40mm (USA Built Machines) (Prior to SN
0200116600)
102
0700616
2
Bolt M6 x 40mm (Belgium Built Machines) (Prior to SN
1200001241)
103
Purchase Item 16
1
Tray, Battery
104
3340975
2
Pad, Wear
105
3860111
2
Roller (USA Built Machines) (Prior to SN 0200116600)
105
3860111
2
Roller (Belgium Built Machines) (Prior to SN 1200001241)
106
4811700
2
Flatwasher M6 (USA Built Machines) (Prior to SN 0200116600)
106
4811700
2
Flatwasher M6 (Belgium Built Machines) (Prior to SN
1200001241)
107
3290605
2
Locknut (USA Built Machines) (SN 0200116600 to Present)
107
3290605
2
Locknut (Belgium Built Machines) (SN 1200001241 to Present)
108
Ref
Battery Box Stop Options (USA Built Machines): (SN
0200116600 to Present)
108
Ref
Battery Box Stop Options (Belgium Built Machines): (SN
1200001241 to Present)
Ref
NOTE: Requires (2) 3820032 Rivet and (1) 4811600 Washer
108
4220252
1
LH (was p/n 4220208)
108
4220253
1
RH (was p/n 4220208)
Ref
NOTE: Old design rollers are not interchangeable with new
design stops. Complete Tray Assembly # 0273698 must be
purchased if upgrading to new design Battery Box Stops.
