SECTION 1 - FRAME
22 1930ES,2030ES,2630ES,2646ES,3246ES,PRIOR TO SN 0200135154 3121246
ITEM PART NUMBER QTY DESCRIPTION REV
21E 1001094301 2 Clamp (Used as part of Service Update on
2030ES/2630ES/2646ES/3246ES)
21 Ref UL Spec
21F 1320162 1 Clamp (Available on All Models)
21G 1001091492 1 Clamp (Used as part of Service Update on 1930ES)
21H 1001094301 2 Clamp (Used as part of Service Update on
2030ES/2630ES/2646ES/3246ES)
22 4191709 1 Bolt M6 x 25mm
23 4340751 Ref Mount, Cable Clamp Options:
23 4340751 AR Mount, Cable Clamp - Non-UL Spec (1930ES Only)
23 4340751 1 Mount, Cable Clamp - UL Spec
24 4811900 1 Flatwasher M8
25 Ref Bolt M6 Options:
25 0760606 1 Bolt M6 1930ES/2030ES/2630ES (12mm Length)
25 0700608 1 Bolt M6 2646ES/3246ES (16mm Length)
26 3290605 AR Locknut M6
27 1321283 AR Clamp, Hose (2646ES/3246ES Only)
28 4811702 AR Flatwasher M6 Wide(Non-UL Spec)
29 4831700 AR Lockwasher M6 (Non-UL Spec)
Ref Items 51 - 56 may be used on machines with service update
kits.
51 1001094124 1 Block, Spacer (1930ES Only)
52 0700624 1 Bolt M6 x 80mm
53 0700619 2 Bolt M6 x 55mm
54 4751400 AR Flatwasher 1/4in Wide
55 4811700 AR Flatwasher M6
56 3290606 AR Locknut M6
Ref ALARM INSTALLATIONS
0272810 Ref ANSI Spec F
0273443 Ref Australian Spec B
0272811 Ref CE Spec D
0272722 Ref Descent Alarm A
0272913 Ref Motion Alarm A
101 4922861 1 Harness, Chassis (Not Shown - ELECTRICAL SECTION for
Breakdown) (USA Built Machines) (Prior to SN 0200126538)
101 4922861 1 Harness, Chassis (Not Shown - ELECTRICAL SECTION for
Breakdown) (Belgium Built Machines) (Prior to SN 1200003119)
102 0140043 1 Alarm
103 4191706 2 Screw M6 x 12mm
