SECTION 1 - FRAME
3121246 1930ES,2030ES,2630ES,2646ES,3246ES,PRIOR TO SN 0200135154 37
FIGURE 1-10. LADDERS, BEACON LIGHT AND ROTARY SENSOR COVER INSTALLATIONS
ITEM PART NUMBER QTY DESCRIPTION REV
Ref LADDER INSTALLATIONS
0272887 Ref Ladder Installations 2030ES B
0272888 Ref Ladder Installations 2630ES B
Ref Note: Not Required on Other Models
101 0701016 4 Bolt M10 x 40mm
102 3291005 4 Locknut M10
103 4420070 3 Tape, Anti-Skid
104 Ref Ladder Options:
104 4846812 1 Ladder 2030ES
104 4846813 1 Ladder 2630ES
Ref BEACON LIGHT INSTALLATIONS
0272309 Ref Beacon Light Installations 1930ES (Not Shown) D
0274012 Ref Beacon Light Installations 2030ES/2630ES B
0272980 Ref Beacon Light Installations 2646ES/3246ES D
201 0760410 2 Bolt M4 x 20mm
202 Ref Bracket Options:
202 0902905 1 Bracket 1930ES
202 0903086 1 Bracket 2030ES/2630ES
202 0902906 1 Bracket 2646ES/3246ES
203 2920161 1 Light, Beacon
203 7016319 1 Bulb, Replacement
203 7016372 1 Len, Replacement
204 3290405 2 Locknut M4
205 4060865 1 Guard
206 4191707 2 Screw M6 x 16mm
207 4811400 2 Flatwasher M4 (USA Built Machines) (Prior to SN 0200128068)
207 4811400 2 Flatwasher M4 (Belgium Built Machines) (Prior to SN
1200002847)
208 4811700 AR Flatwasher M6
209 4750800 2 Flatwasher #8 (Wide) (USA Built Machines) (SN 0200128068
through 0200135154)
209 4750800 2 Flatwasher #8 (Wide) (Belgium Built Machines) (SN 1200002847
through 1200004293)
Ref ROTARY ANGLE SENSOR COVER KIT
Ref Note: This kit is an optional aftermarket add-on for USA Built
Machines SN 0200117602 to Present Only and Belgium Built
Machines SN 1200001665 to Present Only. Not Available on
previous SNs due to changes in frame design. Kit also
includes instructions. Parts listed below are for service.
1001105108 Ref Rotary Angle Sensor Cover Kit 1930ES/2030ES/2630ES
1001105109 Ref Rotary Angle Sensor Cover Kit 2646ES/3246ES
301 Ref Cover Options:
301A 1001103029 1 Cover for 1930ES/2030ES/2630ES
301B 1001103030 1 Cover for 2646ES/3246ES
302 Ref Bolt M6 Options:
302A 0760610 2 Bolt 20mm Length for 1930ES/2030ES/2630ES
302B 0760612 2 Bolt 25mm Length for 2646ES/3246ES
303 4811700 4 Flatwasher 6mm
304 3290605 2 Locknut M6
