SECTION 1 - FRAME
3121246 1930ES,2030ES,2630ES,2646ES,3246ES,PRIOR TO SN 0200135154 31
FIGURE 1-8. BATTERY CHARGER ASSEMBLY AND INSTALLATION (MAC CHARGER WITH
BREAKERS ON END)
ITEM PART NUMBER QTY DESCRIPTION REV
Ref BATTERY CHARGER ASSEMBLY
0400220 Ref All Specs Except Japanese Spec B
0400221 Ref Japanese Specs Only B
2 7018577 2 Capacitor
5 Ref Case Cover, Replacement Options:
5 7022951 1 Cover All Specs Except Japanese Spec
5 7022958 1 Cover Japanese Specs Only
6 Ref Circuit Breaker, AC Options:
6 7018514 2 Circuit Breaker All Specs Except Japanese Spec
6 7018597 1 Circuit Breaker Japanese Specs Only
8 4460227 1 Receptacle, Female - 2 Position (was p/n 7011621)
8 4460267 2 Pin, Male
9 7022952 1 Card, Circuit
10 7022953 1 Cord, DC
11 7022942 1 Fuse Assembly
12 7018570 1 Fuse
13 Not Available 1 Handle
14 7022954 1 Harness
15 7022955 1 Harness
16 7022956 1 Interlock Assembly (Includes Item 3)
18 7022957 1 Plug, Inlet
19 7020673 1 Rectifier
20 7018564 1 Relay
21 7020674 1 Shunt Assembly
22 Ref Connector, Strain Relief Options:
22 7022947 1 Connector All Specs Except Japanese Spec
22 7011528 1 Connector Japanese Specs Only
23 7018586 1 Switch, Slide
25 Ref Transformer Options:
25 7022948 1 Transformer All Specs Except Japanese Spec
25 7022959 1 Transformer Japanese Specs Only
26 Ref Varistor Assembly Options:
26 7018589 1 Varistor Assembly All Specs Except Japanese Spec
26 7020603 1 Varistor Assembly Japanese Specs Only
27 Not Available Varistor
28 4460899 1 Receptacle, Female - 6 Position
28 4460464 6 Pin, Male
29 70002271 1 Relief, Strain
Ref BATTERY CHARGER INSTALLATION
0272874 Ref AC Cable Has Factory Supplied Plug (All Specs Except
Japanese Specs) G
0273681 Ref AC Cable Has Factory Supplied Plug (Japanese Specs) B
0272875 Ref AC Cable Has Locally Supplied Plug (All Specs) F
101 Ref Battery Charger Assembly Options (See Items 1-28 for
Breakdown):
101 0400220 1 Battery Charger Assembly All Specs Except Japanese Specs
101 0400221 1 Battery Charger Assembly Japanese Specs Only
102 Ref Cable, AC Options:
102 1060688 1 Cable, AC - Factory Supplied Plug
