SECTION 2 - GROUND COMPONENTS
3121246 1930ES,2030ES,2630ES,2646ES,3246ES,PRIOR TO SN 0200135154 57
FIGURE 2-5. BRAKE DISCONNECT/RELEASE AND MDI (MULTIFUNCTION DIGITAL INDICATOR)
GAUGE INSTALLATIONS (OPTIONAL)
ITEM PART NUMBER QTY DESCRIPTION REV
Ref NOTE: Items 1-4 or 101 & 102 were factory installed options
for machines with these S/Ns. Machines may be upgraded to
include an MDI (Multifunction Digital Indicator) Gauge by
installing p/n 1001098781 (Items 201- 210).
0275603 Ref BRAKE RELEASE SWITCH INSTALLATION A
1 1706679 1 Decal - Brake Release
2 0903598 1 Bracket
3 4360387 1 Switch, Push Button
4 4191706 2 Screw M6 x 12mm
0275432 Ref BRAKE RELEASE ONLY INSTALLATION A
101 2902331 1 Mount and Screw Kit
102 4922944 1 Bracket Disconnect/Release Switch Assembly (See ELECTRICAL
SECTION for Breakdown as Design May Vary)
1001098781 Ref MDI (MULTIFUNCTION DIGITAL INDICATOR) GAUGE AND
BRAKE RELEASE SERVICE UPGRADE KIT A
201 0100011 AR Compound, Locking
202 0100048 AR Grease, Dielectric
203 1706679 1 Decal - Brake Release
204 4031607 2 Capscrew M5 x 16mm
205 4360387 1 Switch, Push Button
206 4811600 2 Flatwasher M5
207 1001092454 1 Gauge, MDI (Multifunction DIgital Indicator)
208 1001093556 1 MDI Harness (Not Shown - See ELECTRICAL SECTION for
Breakdown)
209 1001094203 1 Bracket
210 1001094359 1 Decal - Troubleshooting (Not Shown - Located on Platform Placard
Plate)
