Page 35
SECTION 1 - FRAME
3121246
1930ES,2030ES,2630ES,2646ES,3246ES,PRIOR TO SN 0200135154
35
FIGURE 1-9. BATTERY CHARGER WITH INVERTER ASSEMBLY AND INSTALLATION (OPTIONAL ON
ANSI SPEC MACHINES)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
BATTERY CHARGER ASSEMBLY
2902502
Ref
Battery Charger Assembly 1930ES
A
0275104
Ref
Battery Charger Assembly 2030ES/2630ES
B
0275105
Ref
Battery Charger Assembly 2646ES/3246ES
B
1
0100011
AR
Compound, Locking
2
1001093839
1
Charger/Inverter Assembly (was p/n 0400237)
3
Ref
Hardware Options:
3
0760812
4
Bolt M8 x 25mm
3
0760814
4
Bolt M8 x 30mm
3
3290805
4
Nut M8
4
0902780
1
Bracket, Mounting (Remote Switch)
5
Ref
Bracket, Mounting (Charger/Inverter)
5
0903410
1
Bracket, Mounting (Charger/Inverter) 1930ES
5
0903319
1
Bracket, Mounting (Charger/Inverter)
2030ES/2630ES/2646ES/3246ES
6
1320043
1
Clamp
7
1705052
1
Decal - On/Off
8
2820239
1
Insulation, Charger Mounting
9
4191707
AR
Screw M6 x 16mm
10
4811700
2
Flatwasher M6
11
4740562
4
Washer, Special
18
1706749
1
Decal - Inverter (Not Shown - Located on Frame Near Inverter)
19
Ref
Decal - Hazardous Voltage Options (Not Shown - Located on
Platform Near AC Box):
19
1706765
1
Decal - Hazardous Voltage English Language
19
1001136847
1
Decal - Hazardous Voltage Spanish Language
