SECTION 2 - GROUND COMPONENTS
3121246
1930ES,2030ES,2630ES,2646ES,3246ES,PRIOR TO SN 0200135154
41
FIGURE 2-1. BATTERIES AND COVERS INSTALLATION (USA BUILT MACHINES AND BELGIUM
BUILT MACHINES) (Prior to SN 0200128413, Prior to SN 1200002974)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
BATTERIES AND COVERS INSTALLATION
0272719
Ref
Batteries and Covers Installation 1930ES (220 A-HR)
J
0274222
Ref
Batteries and Covers Installation 1930ES (220 A-HR) (Lock)
B
0274221
Ref
Batteries and Covers Installation 1930ES (220 A-HR) (UL
Spec) (Lock)
B
0272827
Ref
Batteries and Covers Installation
2030ES/2630ES/2646ES/3246ES (220 A-HR) (Standard)
J
0274215
Ref
Batteries and Covers Installation
2030ES/2630ES/2646ES/3246ES (220 A-HR) (Lock)
B
0274214
Ref
Batteries and Covers Installation
2030ES/2630ES/2646ES/3246ES (220 A-HR) (UL Spec) (Lock)
B
0272720
Ref
Batteries and Covers Installation
2030ES/2630ES/2646ES/3246ES (245 A-HR) (Hi-Output)
J
0274217
Ref
Batteries and Covers Installation
2030ES/2630ES/2646ES/3246ES (245 A-HR) (Hi-Output) (Lock)
B
0274216
Ref
Batteries and Covers Installation
2030ES/2630ES/2646ES/3246ES (245 A-HR) (Hi-Output) (UL
Spec) (Lock)
B
0272878
Ref
Anti-Vandelism Package Installation
A
1
Ref
Battery Options:
1
0400215
4
Battery Type GC Type with 225 AH Rating
1
0400216
4
Battery Type EV Type with 244 AH Rating (Not Available on
1930ES)
2
4031713
2
Bolt M6 x 40mm
3
0760610
8
Bolt M6 x 20mm
5
Ref
Cover Options:
Ref
Note: When replacing P/N 1671096 for service, drill 7mm holes
to 11mm diameter.
5
2915029
2
Cover (Standard) (was p/n 1671096, 1671155 & 1671196)
5
2915030
2
Cover (Lockable) (was p/n 1671175 & 1671197)
5
2915031
2
Cover (Lockable) (UL Spec) (was p/n 1671180)
5A
2940151
4
Latch, Standard (2 Per Cover)
5A
2940153
4
Latch, Anti-Vandelism Lockable (2 Per Cover)
5A
7027862
AR
Key
7
Ref
Battery Cable Kit Options (Not Shown - See ELECTRICAL
SECTION for Breakdown):
7
2902239
1
Battery Cable Kit 1930ES
7
2902248
1
Battery Cable Kit 2030ES/2630ES/2646ES/3246ES
8
Ref
Plate, Slide Stop Options:
8
3574981
2
LH (was p/n 3574427)
8
3574984
2
RH (was p/n 3574427)
9
3290605
2
Locknut M6
10
3574428
4
Plate, Latch
12
4191706
8
Screw M6 x 12mm
13
4191707
8
Screw M6 x 16mm
14
4811700
8
Flatwasher M6
16
0273698
2
Tray Assembly (was p/n 0273110) (See Items 101-106 for
Breakdown)
19
4240172
4
Strap, Battery (UL Spec - Not Shown)
Ref
TRAY ASSEMBLY OPTIONS:
0273110
Ref
USA Built Machines (Prior to SN 0200116600)
D
