SECTION 2 - GROUND COMPONENTS
3121246 1930ES,2030ES,2630ES,2646ES,3246ES,PRIOR TO SN 0200135154 45
FIGURE 2-2. BATTERIES AND COVERS INSTALLATION (USA BUILT MACHINES AND BELGIUM
BUILT MACHINES) (SN 0200128413 through 0200135154, SN 1200002974 through 1200004293)
ITEM PART NUMBER QTY DESCRIPTION REV
Ref BATTERIES AND COVERS INSTALLATION
Ref GC Type with 225 AH Rating Batteries:
0272719 Ref Batteries and Covers Installation 1930ES (Standard Covers) L
0274222 Ref Batteries and Covers Installation 1930ES (Lockable Covers) D
0274221 Ref Batteries and Covers Installation 1930ES (UL Spec)
(Lockable Covers) D
0272827 Ref Batteries and Covers Installation
2030ES/2630ES/2646ES/3246ES (Standard Cover) L
0274215 Ref Batteries and Covers Installation
2030ES/2630ES/2646ES/3246ES (Lockable Cover) D
0274214 Ref Batteries and Covers Installation
2030ES/2630ES/2646ES/3246ES (UL Spec) (Lockable Covers) D
Ref EV Type with 244 AH Rating Batteries:
0272720 Ref Batteries and Covers Installation
2030ES/2630ES/2646ES/3246ES (Standard Covers) L
0274217 Ref Batteries and Covers Installation
2030ES/2630ES/2646ES/3246ES (Lockable Covers) D
0274216 Ref Batteries and Covers Installation
2030ES/2630ES/2646ES/3246ES (UL Spec) (Lockable Covers) D
1 Ref Battery Options:
1 0400215 4 Battery GC Type with 225 AH Rating
1 0400216 4 Battery EV Type with 244 AH Rating (Not Available on
1930ES)
2 Ref Bolt Options:
2 0760616 AR Bolt M6 x 40mm, Hexhead
2 4031713 AR Bolt M6 x 40mm, Sockethead
3 0760610 8 Bolt M6 x 20mm
8 Ref Plate, Slide Stop Options:
8 3574981 Plate, Slide Stop - Left Side
8 3574984 Plate, Slide Stop - Right Side
9 3290605 AR Locknut M6
13 4191707 8 Screw M6 x 16mm
14 4811700 8 Flatwasher M6
16 Ref Tray Assembly Options (See Items 101-106 for Breakdown):
16 0273698 2 Tray - USA and Belgium
16 0861678 2 Tray - UL Spec
17 Ref Cover Options:
17 Ref USA Built Machines (SN 0200128413 through 0200130606)
17 Ref Belgium Built Machines (SN 1200002974 through
1200003526)
17 2915029 2 Cover - Standard (was p/n 1671196)
17 2915030 2 Cover - Lockable (was p/n 1671197)
17 1671204 2 Cover - UL Spec - Lockable (was p/n 1671200)
17 Ref USA Built Machines (SN 0200130607 through 0200135154)
17 Ref Belgium Built Machines (SN 1200003527 through
1200004293)
17 1671202 2 Cover - Standard
17 1671204 2 Cover - Lockable
17 1671204 2 Cover - UL Spec - Lockable (was p/n 1671200)
17A Ref Latch Options (2 Per Cover):
17A 2940174 4 Standard
