JLG 3246ES Parts Manual - Manual (Page 19)

SECTION 1 - FRAME
3121246 1930ES,2030ES,2630ES,2646ES,3246ES,PRIOR TO SN 0200135154 19
ITEM PART NUMBER QTY DESCRIPTION REV
108B 1001134012 1 Harness, Electrical Cable 2030ES/2630ES/2646ES/3246ES
(was p/n 1001091843)
109 70000792 1 Commutator
110 Item 209 1 Disc, Reaction
111 7024785 1 Disc, Friction
112 Item 209 1 Brake Assembly
113 See Note 2 Flatwasher (Note: Use Item 210A or 210B)
114 See Note 2 Bolt (Note: Use Item 210A or 210B)
Ref Style "A" Brake Cover
125 See Note 1 Plate, Cover (Note: Use Item 211A or 211B)
126 See Note 1 O-Ring (Note: Use Item 210A, 210B, 211A or 211B)
127 70000383 1 Connector, Strain Relief
128 See Note 1 Cover (Note: Use Item 211A or 211B)
Ref Style "B" Brake Cover
151 See Note 1 Plate, Cover (Note: Use Item 211A or 211B)
152 70001949 1 Gasket, Cover
153 See Note 1 Cover, Top (Note: Use Item 211A or 211B)
154 See Note 1 Cover, End (Note: Use Item 211A or 211B)
Ref KIT OPTIONS
201 7024747 1 Cover Kit (Includes Items 11, 19, 20, 21 & 29)
202 7024748 1 Main Seal Kit (Includes Qty 1 of Items 14, 16 & 20)
203 7024749 1 Input Carrier Kit (Includes Items 4-8, 18, 20 & 23-26)
204 7024758 1 Input Ring Kit (Includes Item 3, 20, 27 & Qty 1 of Item 14)
205 Ref Motor Kit Options (Includes Items 13, 17, 103-114 & 151-154):
205 Ref Motors with Item #108A Style Electrical Cable
205A 1001100819 1 Motor Kit 1930ES (was p/n 7024774)
205B 1001100820 1 Motor Kit 2030ES/2630ES/2646ES/3246ES (was p/n
7024777)
205 Ref Motors with Item #108B Style Electrical Cable
205C 70001263 1 Motor Kit 1930ES
205D 70001345 1 Motor Kit 2030ES/2630ES/2646ES/3246ES
206 7024756 1 Hub Kit (Includes Items 2, 16, 20, 27 & Qty 1 of Item 14)
207 7024750 1 Output Planet Kit (Includes Items 9, 10, 15, 20, 25-28, 32 & Qty 1
of Item 14)
208 7024771 1 Motor Brush and Bearing Kit (Includes Items 103, 106 & 107)
209 7024772 1 Brake Kit (Includes Items 110, 111 & 112)
210 Ref Motor Hardware Kit (Includes 113 & 114)
210A 7024773 1 Motor Hardware Kit 1930ES
210B 7024776 1 Motor Hardware Kit 2030ES/2630ES/2646ES/3246ES
211 Ref Brake Cover Kit Options:
211A 7024787 1 Style "A" (Includes Items 125 - 128)
211B 70001265 1 Style "B" (Includes Items 151 - 154)
