SECTION 3 - SCISSORS ARMS
72
1930ES,2030ES,2630ES,2646ES,3246ES,PRIOR TO SN 0200135154
3121246
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
52
1180380
2
Carrier, Cable
53
4812000
2
Washer, 10mm
54
4071094
AR
Shim, Spacer
55
3423170
1
Pin
56
3291007
1
Locknut M10
2902236
1
Scissor Arm Kit - 2646ES/3246ES (Includes Items 1-10,17,18,36,
49,51 & 52)
L
Ref
SCISSOR ARMS INSTALLATIONS - 2646ES/3246ES
0272623
Ref
Scissor Arms Installations 2646ES
D
0272622
Ref
Scissor Arms Installations 3246ES
D
102
0701022
2
Bolt M10 x 70mm
103
3200453
1
Mount, Switch
104
3200454
1
Mount, Switch
105
3291005
2
Locknut M10
106
3300474
2
Locknut M4
107
3340957
2
Pad, Slide
108
3423016
1
Pin, Sensor
109
3423017
1
Pin
110
3900334
2
Screw M4
111
4191706
3
Screw M6 x 12mm
112
4191709
2
Screw M6 x 25mm
113
4360502
1
Switch, Proximity Sensor
114
1001092354
1
Switch, Rotary Angle Sensor (was p/n 4360526)
118
4420070
2
Tape, Anti-Skid
