SECTION 2 - TURNTABLE
3121291 450A Series II/450AJ Series II 95
ITEM PART NUMBER QTY DESCRIPTION REV
530 70024918 1 Sender, Temperature (Not Shown - Located Top Front)
531 70024504 1 Sensor, Pressure (Not Shown - Located Left Side Front)
531 70024920 1 Seal
532 See Note 1 Muffler (Note: Not Available at Time of Printing)
532 70004286 1 Outlet, Muffler
1001146715 Ref SPARK ARRESTER INSTALLATION (OPTIONAL) A
601 1001146714 1 Arrester, Spark
1001162335 Ref BRACKET ASSEMBLY (LESS FUEL PUMP AND FILTER) B
701 0100011 AR Locking, Compound
702 0641610 2 Bolt 3/8in-16NC x 1-1/4in
703 0721006 4 Bolt #10-24NC x 3/4in
704 1001154405 1.5
ft/0.4m
Hose
705 3311001 4 Nut #10-20NC
706 3311605 2 Locknut 3/8in-16NC
707 4711000 8 Flatwasher #10 Thin
708 4711600 4 Flatwasher 3/8in Thin
709 8405006 2 Clamp
710 1001141870 1 Plate, Fuel Pump Mount
711 1001142501 1 Fitting, Elbow Barbed
