SECTION 3 - BOOM
144
450A Series II/450AJ Series II
3121291
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
65
1001140278
1
Without Arctic Package
65
1001138817
1
With Arctic Package
66
Ref
Level (Platform Slave) Cylinder Assembly (See CYLINDER
SECTION for Breakdown)
66
1001140279
1
Without Arctic Package
66
1001138815
1
With Arctic Package
67
Ref
Jib Lift Cylinder Assembly (See CYLINDER SECTION for
Breakdown)
67
1001140282
1
Without Arctic Package
67
1001138816
1
With Arctic Package
68
1001143918
1
Main Boom Assembly (See MAIN BOOM ASSEMBLY for
Breakdown)
Ref
BOOM CABLES AND CLAMPS INSTALLATIONS
0271122
Ref
ANSI/ANSI Export /CSA Specs without SkyPower
J
0271206
Ref
Australian/CE Specs without SkyPower
J
0275116
Ref
Without SkyPower with Arctic Package
D
1001115917
Ref
Without SkyPower with Communication System
A
0273280
Ref
With SkyPower
C
0275786
Ref
With SkyPower with Arctic Package
C
1001116516
Ref
With SkyPower with Communication System
A
Ref
Note: For Additional Components See ELECTRICAL
SECTION
102
Ref
Block, Clamp Options:
102
0561459
2
Without Arctic Package
102
1321696
2
With Arctic Package
105
0641506
2
Bolt 5/16in-18NC x 3/4in (With SkyPower Only)
107
1320202
2
Clamp (With SkyPower Only)
112
3300151
6
Nut, Acorn 1/4in-20NC
114
3311401
6
Nut 1/4in-20NC
115
3311505
2
Locknut 5/16in-18NC (With SkyPower Only)
117
3571462
1
Shield
118
3574532
2
Plate, Clamp Mounting (With SkyPower Only)
130
4751400
12
Flatwasher 1/4in Regular
131
4751500
4
Flatwasher 5/16in Regular (With SkyPower Only)
134
Ref
Harness, Main Boom Options (Not Shown - See ELECTRICAL
SECTION):
134
4922532
1
Without Arctic Package
134
4923459
1
With Arctic Package
135
Ref
Cable, Electrical (Not Shown - See ELECTRICAL SECTION)
135
1060988
1
Without SkyPower (12/3 AC Power Cable)
135
4923481
1
With Arctic Package (12/3 AC Power Cable)
135
4922857
1
With SkyPower (8/5 AC Power Cable)
135
4922929
1
With Arctic Package with SkyPower(8/5 AC Power Cable)
135
4922929
1
With Communication System with SkyPower(8/5 AC Power
Cable)
136
1001115916
AR
Cable, Communication (with Communication System Only) (Not
Shown)
