SECTION 4 - PLATFORM
3121291 450A Series II/450AJ Series II 167
FIGURE 4-2. FALL ARREST PLATFORM COMPONENTS INSTALLATION (OPTIONAL)
ITEM PART NUMBER QTY DESCRIPTION REV
Ref PLATFORM ASSEMBLY (FALL ARREST)
3510884 Ref Platform Assembly (Fall Arrest) 450A Series II E
1001112103 Ref Platform Assembly (Fall Arrest) 450AJ Series II (Use p/n
1001144598) - USA Built Machines (Prior to SN 0300185907) B
1001112103 Ref Platform Assembly (Fall Arrest) 450AJ Series II (Use p/n
1001144598) - Romanian Built Machines (Prior to SN
E300001713) B
1001144598 Ref Platform Assembly (Fall Arrest) 450AJ Series - USA Built
Machines (SN 0300185907 to Present) A
1001144598 Ref Platform Assembly (Fall Arrest) 450AJ Series - Romanian
Built Machines (SN E300001713 to Present) A
Ref Note: Only Available on ANSI and CSA Specs.
1 0681822 4 Bolt 1/2in-13NC x 2-3/4in (Grade 8)
2 Ref Cable, Fall Arrest Options:
2 1060919 1 Cable, Fall Arrest 450A Series II
2 1001112943 1 Cable, Fall Arrest 450AJ Series II
3 1705014 1 Decal - Safety
4 1706385 1 Decal - Drop Bar
5 2410014 1 Gate Weldment
6 3271805 6 Locknut 1/2in-13NC (Grade 8)
7 3311605 1 Locknut 3/8in-16NC
8 See Note 1 Platform Weldment (Note: Purchase Platform Assembly)
9 3520072 1 Cap-Plug
10 3900054 1 Bolt 1/2in-13NC x 1-3/4in
11 4751800 8 Flatwasher 1/2in Regular
12 0962270 2 Bearing, Oilite
13 0681814 4 Bolt 1/2in-13NC x 1-3/4in (Grade 8)
14 4711800 2 Flatwasher 1/2in Narrow
