SECTION 2 - TURNTABLE
66
450A Series II/450AJ Series II
3121291
FIGURE 2-7. CATERPILLAR ENGINE INSTALLATION (ROMANIAN BUILT MACHINES)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
USA Built Machines use SNs 03xxxxxxxx.
Ref
Romanian Built Machines use SNs E3xxxxxxxx.
1001141999
Ref
CATERPILLAR ENGINE ASSEMBLY
A
1
0080181
1
Adaptor, Pump Mounting Plate
2
0080201
1
Elbow, Rubber
3
0100011
AR
Compound, Locking
4
0340041
2
Band, Air Cleaner Mounting
5
0340046
2
Band, Muffler Mounting
6
0630569
9
Bolt M14 x 30mm
7
0641406
8
Bolt 1/4in-20NC x 3/4in
8
0641408
3
Bolt 1/4inin-20NC x 1in
9
0641410
2
Bolt 1/4in-20NC x 1-1/4in
10
0641506
8
Bolt 5/16in-18NC x 3/4in
11
0641507
6
Bolt 5/16in-18NC x 7/8in
12
0641609
5
Bolt 3/8in-16NC x 1-1/8in
13
0641610
39
Bolt 3/8in-16NC x 1-1/4in
14
0641611
2
Bolt 3/8in-16NC x 1-3/8in
15
0641614
2
Bolt 3/8in-16NC x 1-3/4in
16
0641812
2
Bolt 1/2in-13NC x 1-1/2in
17
0641820
4
Bolt 1/2in-13NC x 2-1/2in
18
0741610
2
Screw, Countersunk 3/8in-16NC x 1-1/4in
19
0760815
4
Bolt M8 x 35mm
20
0962172
1
Bushing, Flanged
21
1320012
4
Clamp
22
1320016
4
Clamp
23
1320022
3
Clamp
24
1320058
1
Clamp
25
1320223
5
Clamp
26
1320318
2
P-Clamp
27
1340060
1
Air Cleaner Assembly
27
7012664
1
Element, Air Cleaner
28
1580011
1
Container, Coolant Overflow
29
1660255
1
Coupling, Pump
30
1703162
2
Decal - Caution Fan
31
2151212
2
Fitting, Elbow
32
2220376
1
Fitting, Straight
33
2220383
2
Fitting, Tee
34
2220567
1
Fitting, Elbow
35
2220578
1
Fitting, Elbow
36
2220603
2
Fitting, Straight
37
2220947
1
Fitting, Straight
38
2221026
1
Fitting, Tee
39
2221041
1
Fitting, Tee
40
2720058
2.5
ft/0.8m
Hose
41
2720271
1.25
ft/0.38m
Hose
42
2720615
1.5
ft/0.46m
Hose
43
3200378
4
Mount, Motor
