SECTION 5 - CYLINDER
3121291 450A Series II/450AJ Series II 195
FIGURE 5-5. USA BUILT MACHINES/LIFT (JIB) CYLINDER (450AJ SERIES II WITHOUT ARCTIC
PACKAGE)
ITEM PART NUMBER QTY DESCRIPTION REV
Ref USA Built Machines use SNs 03xxxxxxxx.
Ref Romanian Built Machines use SNs E3xxxxxxxx.
1001140282 Ref LIFT (JIB) CYLINDER ASSEMBLY (450AJ SERIES II WITHOUT
ARCTIC PACKAGE) A
1 70003834 1 Barrel
2 70003835 1 Rod
6 7026088 1 Head
7 70003833 1 Piston
8 0961951 2 Bushing
9 0961947 2 Bushing
11 4640509 2 Cartridge, Counterbalance Valve
11 2900792 2 Seal Kit - 4640509 Valve
14 7026090 2 Bushing
15 7026091 1 Sleeve
16 7026092 1 Nut
17 70002223 1 Retainer
18 70003836 1 Wiper
19 70003836 1 Seal
20 70003836 1 O-Ring
21 70003836 1 Ring, Backup
22 70003836 1 O-Ring
23 70003836 1 O-Ring
24 7026068 1 O-Ring
25 7024844 2 Plug
28 70003836 1 O-Ring
29 70003836 1 Seal
31 70002220 1 Ring, Retaining
32 70003836 2 Ring, Wear
50 70003836 1 Seal Kit - 1001140282 Cylinder (Includes Items 18-23, 28, 29 &
32)
