SECTION 2 - TURNTABLE
3121291
450A Series II/450AJ Series II
51
FIGURE 2-3. TURNTABLE AND SWING DRIVE INSTALLATIONS
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
SWING DRIVE INSTALLATIONS
0273358
Ref
SWING DRIVE INSTALLATION (DOHI)
D
1001153365
Ref
SWING DRIVE INSTALLATION (JING WEI)
A
1
0100019
AR
Compound, Locking
2
Ref
Swing Bearing and Rotation Box Assembly Options (See SWING
BEARING AND ROTATION BOX ASSEMBLY for Breakdown):
2
0440272
1
DOHI (Original Equipment) (Use p/n 1001160532)
2
1001160532
1
JING WEI (Service Replacement Kit Includes Items Bearing 3-6
& 9)
2
1001153016
1
JING WEI
Ref
Note: Original Equipment Bearing p/n 0440272 may have been
replaced with Service Replacement Bearing Kit p/n
1001160532. Visually identify the p/n tag on bearing before
ordering parts.
3
3931832
2
Bolt 1/2in-13NC x 2in
4
0682040
18
Bolt 5/8in-11NC x 5in (Grade 8)
5
0682048
24
Bolt 5/8in-11NC x 6in (Grade 8)
6
2160001
2
Fitting, Grease
7
1001104850
1
Swing Motor Assembly (See SWING MOTOR ASSEMBLY for
Breakdown)
8
4740171
2
Flatwasher 1/2in Special
9
4892000
42
Flatwasher 5/8in Hardened
1001102695
Ref
DRIVE ORIENTATION INSTALLATION
D
101
0100011
AR
Compound, Locking
102
0641406
1
Bolt 1/4in-20NC x 3/4in
103
0641606
2
Bolt 3/8in-16NC x 3/4in
104
88261039
2
Screw 3/8in-16NC x 2in
105
1320041
1
Clamp
106
3311005
2
Locknut #10
107
3311405
1
Locknut 1/4in-20NC
108
3931010
2
Screw #10-24 x 5/8in
109
4360517
1
Switch, Proximity
110
4711000
2
Flatwasher #10 Regular
111
4711400
1
Flatwasher 1/4in Thin
112
4711600
4
Flatwasher 3/8in Thin
113
1001145163
2
Spacer (was p/n 7116691 & 1001114757)
114
1001102526
1
Cam
115
1001102527
1
Bracket, Switch
116
4740120
2
Flatwasher, Special
