SECTION 6 - HYDRAULIC
3121291
450A Series II/450AJ Series II
235
FIGURE 6-2. AXLE LOCKOUT HYDRAULIC DIAGRAM - 4WD
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
USA Built Machines use SNs 03xxxxxxxx.
Ref
Romanian Built Machines use SNs E3xxxxxxxx.
Ref
AXLE LOCKOUT HYDRAULIC DIAGRAM
1001138685
Ref
USA Built Machines
B
1001140559
Ref
Romanian Built Machines
B
1
2220415
3
Fitting, Straight
3
2220371
5
Fitting, Straight
4
2220466
2
Fitting, Elbow
5
1001138697
1
Fitting, Straight
6
2220502
1
Fitting, Elbow
7
2220504
1
Fitting, Tee
8
2220490
1
Fitting, Tee
9
1001138688
1
Hose
10
1001138689
1
Hose
11
Ref
Hose Options:
11
1001138690
2
USA Built Machines
11
1001140537
2
Romanian Built Machines
13
Ref
Hose Options:
13
1001138694
1
USA Built Machines
13
1001140692
1
Romanian Built Machines
14
Ref
Hose Options:
14
1001138691
2
USA Built Machines
14
1001140693
2
Romanian Built Machines
15
2220473
2
Fitting, Elbow
16
8902175
1
Valve, Shuttle
18
2220235
1
Plug
21
1001143486
2
Hose
22
Ref
Hose Options:
22
1001140562
1
USA Built Machines
22
1001138688
1
Romanian Built Machines
