SECTION 2 - TURNTABLE
3121291
450A Series II/450AJ Series II
121
FIGURE 2-18. LIGHT INSTALLATIONS
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001145514
Ref
STROBE LIGHT INSTALLATION (AMBER) (OPTIONAL)
B
Ref
Note: If machine is equipped with BLUE Strobe Light, See
SPECIAL OPTIONS SECTION SkyGuard Kit
1
0100011
AR
Compound, Locking
2
0100048
AR
Sealant, Silicone
3
2920161
1
Strobe Light Assembly
3
7016319
1
Bulb, Replacement
3
7016372
1
Lens
3
4460891
1
Plug, Male
3
4460265
2
Socket, Female
4
3290405
2
Nut M4
5
0760410
2
Screw M4 x 20mm
6
4060865
1
Guard
7
1001091102
4
Flatwasher M4
8
88662523
2
Nut, Tinnerman
9
1001145564
1
Bracket
Ref
LIGHTS INSTALLATIONS (OPTIONAL)
1001145717
Ref
Headlights and Taillights
A
101
1705170
1
Decal, Lights (Not Shown - Located on Console)
102
2920110
2
Headlight
102
7016628
2
Bulb, Light (1 Per Light)
103
2920113
2
Taillight
104
3311005
4
Nut #10-24NC
105
3911040
4
Screw, Machine #10-24NC x 2-1/2in
106
3960461
2
Gasket
107
4240032
12
Tie-Strap (Not Shown)
108
4360522
1
Switch, Push Button (Not Shown - Located on Console):
109
4460234
12
Mount, Tie-Strap (Not Shown)
110
4740076
2
Washer, Fender
111
4740362
4
Washer, Fender
112
4751000
4
Flatwasher #10 Regular
