SECTION 5 - CYLINDER
3121291 450A Series II/450AJ Series II 199
FIGURE 5-7. USA BUILT MACHINES/LIFT (MAIN BOOM) CYLINDER
ITEM PART NUMBER QTY DESCRIPTION REV
Ref USA Built Machines use SNs 03xxxxxxxx.
Ref Romanian Built Machines use SNs E3xxxxxxxx.
Ref LIFT (MAIN BOOM) CYLINDER ASSEMBLY
1684155 Ref Lift (Main Boom) Cylinder Assembly 450A SERIES II 2-D
1684154 Ref Lift (Main Boom) Cylinder Assembly 450AJ SERIES II 2-D
1 Ref Barrel Weldment Options:
1 1684060 1 1684155 Cylinder
1 1683946 1 1684154 Cylinder
2 Ref Rod Weldment Options:
2 1684059 1 1684155 Cylinder
2 1683947 1 1684154 Cylinder
3 1120108 1 Cap, End
4 3480240 1 Piston
5 1683504 1 Head
6 Ref Nut, Hex Options:
6 3300315 1 1684155 Cylinder
6 3300279 1 1684154 Cylinder
7 Ref Spacer, Tube Options:
7 4567177 1 1684155 Cylinder
7 4567908 1 1684154 Cylinder
9 4640936 1 Cartridge, Valve
9 2900770 1 Seal Kit - 4640936 Valve
10 2220885 1 Plug, O-Ring
11 3900170 1 Setscrew
12 Ref Setscrew Options:
12 3951402 1 1684155 Cylinder
12 3900142 1 1684154 Cylinder
13 1001118241 2 Ring, Wear
14 1001118241 1 Seal
15 1001118241 1 O-Ring
16 1001118241 1 Ring, Wear
17 1001118241 1 O-Ring
18 1001118241 1 Seal
19 1001118241 1 Wiper
20 0100011 AR Compound, Locking
21 0100038 AR Primer, Locking
22 0100035 AR Compound, Locking
23 0961950 4 Bushing
25 1001118241 1 Seal Kit, Cylinder (Includes Items 13-19)
