SECTION 2 - TURNTABLE
58 450A Series II/450AJ Series II 3121291
FIGURE 2-6. CATERPILLAR ENGINE INSTALLATION (USA BUILT MACHINES)
ITEM PART NUMBER QTY DESCRIPTION REV
Ref USA Built Machines use SNs 03xxxxxxxx.
Ref Romanian Built Machines use SNs E3xxxxxxxx.
Ref CATERPILLAR ENGINE ASSEMBLY
1001141721 Ref Machines without Arctic Package A
1001141723 Ref Machines with Arctic Package A
1 0080181 1 Adaptor, Pump Mounting Plate
2 0080201 1 Elbow, Rubber
3 0100011 AR Compound, Locking
4 0340041 2 Band, Air Cleaner Mounting
5 0340046 2 Band, Muffler Mounting
6 0400075 1 Battery, 12V
7 0630569 8 Bolt M14 x 30mm
8 0641405 2 Bolt 1/4in-20NC x 5/8in
9 0641406 8 Bolt 1/4in-20NC x 3/4in
10 0641408 4 Bolt 1/4inin-20NC x 1in
11 0641410 2 Bolt 1/4in-20NC x 1-1/4in
12 0641506 8 Bolt 5/16in-18NC x 3/4in
13 0641507 6 Bolt 5/16in-18NC x 7/8in
14 0641608 2 Bolt 3/8in-16NC x 1in
15 0641609 5 Bolt 3/8in-16NC x 1-1/8in
16 0641610 32 Bolt 3/8in-16NC x 1-1/4in
17 0641611 2 Bolt 3/8in-16NC x 1-3/8in
18 0641614 2 Bolt 3/8in-16NC x 1-3/4in
19 0641820 4 Bolt 1/2in-13NC x 2-1/2in
20 0741608 2 Screw, Countersunk 3/8in-16NC x 1in
21 0760815 4 Bolt M8 x 35mm
22 0962172 1 Bushing, Flanged
23 1320012 4 Clamp
24 1320016 4 Clamp
25 1320022 3 Clamp
26 1320058 1 Clamp
27 1320223 6 Clamp
28 1320318 2 P-Clamp
29 1340060 1 Air Cleaner Assembly
29 7012664 1 Element, Air Cleaner
30 1580011 1 Container, Coolant Overflow
31 1660255 1 Coupling, Pump
32 1703162 2 Decal - Caution Fan
33 2720058 2.5
ft/0.8m
Hose
34 2720271 1.25
ft/0.38m
Hose
35 2720615 1.5
ft/0.46m
Hose
36 3200378 4 Mount, Motor
37 Ref Muffler Options:
37 3220113 1 Standard Spark Arresting Muffler
37 70001017 1 Clamp
37 1001107116 1 Optional Catalytic Muffler (Not Available on Arctic Machines)
37 70002705 1 Clamp
