SECTION 7 - ELECTRICAL
270
450A Series II/450AJ Series II
3121291
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
713
Ref
Platform Worklights Components
713A
2920140
2
Platform Worklights External Harness (Includes Light and Wire
Only)
713B
4460459
1
Connector - 3 Position
713B
4460790
3
Socket, Female
713B
4460789
3
Seal
713C
4460476
1
Receptacle, Female
713C
4460850
3
Pin, Male
713C
4460790
3
Socket, Female
713D
4460426
1
Connector, Strain Relief
713E
2400070
1
Fuse
713E
2400066
1
Holder, Fuse
713F
1060988
1
Worklights Harness (Upper Boom to Worklights)
713G
1060987
1
Worklights Harness (Tower Boom to Aux Power Solenoid)
Ref
TOOLS (NOT SHOWN)
801
7002821
1
Crimper (For Wire to Pin/Socket Connections)
802
7002823
1
Extractor (For Removal of Pin/Socket from Connectors)
803
4460467
1
Extractor, Pin (Blue 16-18 Gauge) (For Removal of Pin/Socket
from Connectors)
804
4460510
1
Extractor, Pin (Yellow 12-14 Gauge) (For Removal of Pin/Socket
from Connectors)
805
7002828
1
Stripper, Wire
806
2901443
1
Analyzer Kit
806A
1600244
1
Analyzer
806B
1060633
1
Cable, Analyzer
1-A
806C
4460321
2
Plug, Male
806C
4460226
8
Socket, Female
807
1001137005
1
Cable Kit, Software (Not Shown)
