SECTION 2 - TURNTABLE
3121291 450A Series II/450AJ Series II 47
FIGURE 2-1. MAIN CONTROL VALVE AND ALARM INSTALLATIONS
ITEM PART NUMBER QTY DESCRIPTION REV
Ref VALVES INSTALLATIONS
1001141803 Ref Valves Installations 450A Series II B
1001141804 Ref Valves Installations 450AJ Series II B
1 0100011 AR Compound, Locking
4 0641607 4 Bolt 3/8in-16NC x 7/8in
5 0651405 3 Bolt 1/4in-24NF x 5/8in
7 2120209 1 Pressure Filter Assembly
7 2120210 Element, Filter
7 7020020 1 Indicator
7 70000934 1 O-Ring, Filter Bowl
8 4751400 3 Flatwasher 1/4in Regular
10 4711600 4 Flatwasher 3/8in Thin
12 1001138771 1 Main Control Valve Assembly (See MAIN CONTROL VALVE
ASSEMBLY for Breakdown)
1001142264 Ref ALARM INSTALLATION C
101 0100011 AR Compound, Locking
102 0100048 AR Sealant, Silicone
103 0140044 1 Alarm/Harness Assembly
104 0641405 3 Bolt 1/4in-20NC x 5/8in
105 1320136 1 Clamp
106 4711400 3 Flatwasher 1/4in Thin
