SECTION 5 - CYLINDER
3121291 450A Series II/450AJ Series II 219
FIGURE 5-17. ROMANIAN BUILT MACHINES/LIFT (JIB) CYLINDER
ITEM PART NUMBER QTY DESCRIPTION REV
Ref USA Built Machines use SNs 03xxxxxxxx.
Ref Romanian Built Machines use SNs E3xxxxxxxx.
1684242 Ref JIB LIFT CYLINDER ASSEMBLY D
1 7026093 1 Barrel
2 7026094 1 Rod
6 7026088 1 Head
7 7026089 1 Piston
8 0961951 2 Bearing
9 0961947 2 Bearing
11 7026096 2 Cartridge, Valve
11 2900770 2 Seal Kit - 7026096 Valve (1 Per Cartridge)
14 7026090 2 Bushing
15 7026091 1 Sleeve
16 7026092 1 Nut
17 70002223 1 Ring, Retaining
18 7026095 1 Wiper
19 7026095 1 Seal
20 7026095 1 O-Ring
21 7026095 1 Ring, Back-up
22 7026095 1 O-Ring
23 7026095 1 O-Ring
24 7026095 1 O-Ring
27 7026095 2 Ring, Ware (SN E300001236 to Present)
28 7026095 1 O-Ring
29 7026095 1 Seal
31 70002220 1 Ring, Retaining
35 7026095 1 Seal Kit, Cylinder (Includes Items 18-24, 27 & 29)
