6-4 3120241
SECTION 6 HYDRAULICS S
E
C
T
I
O
N
6
H
Y
D
R
A
U
L
I
C
S
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
GAS ENGINES WITH RACINE VALVES: Ref.
2790902 Ford with 2-Section Boom Ref. I
2791043 Ford with Steering Wheel and 2-Section Boom Ref. B
2791042 Ford with 3-Section Boom Ref. —
2791041 Ford with Steering Wheel and Oil Cooler Ref. —
2791044
Ford with Steering Wheel, Oil Cooler and 3-Sec-
tion Boom
Ref. —
2791033 Wisconsin without Steering Wheel Ref. A
2791091
Wisconsin with Steering Wheel and 2-Section
Boom
Ref. —
2791094
Wisconsin with Steering Wheel and 3-Section
Boom
Ref. —
2791093
Wisconsin with Steering Wheel, Oil Cooler and 3-
Section Boom
Ref. —
GAS ENGINE WITH VICKERS VALVES AND STAN-
DARD CONTROLS:
Ref.
2791201 Ford without Steering Wheel (Prior to March 1995) Ref. H
2791191
Ford with Steering Wheel and 2-Section Boom
(Prior to March 1995)
Ref. D
2791209
Ford with Steering Wheel and 3-Section Boom
(Prior to March 1995)
Ref. B
2791204 Ford with Oil Cooler (Prior to March 1995) Ref. D
2791193
Ford with Steering Wheel, Oil Cooler and 2-Sec-
tion Boom (Prior to March 1995)
Ref. C
2791210
Ford with Steering Wheel, Oil Cooler and 3-Sec-
tion (Prior to March 1995)
Ref. B
2792198* Ford (March 1995 to Present) Ref. A
2792199 Ford with Oil Cooler (March 1995 to Present) Ref. —
2791206 Wisconsin without Steering Wheel Ref. D
2791198
Wisconsin with Steering Wheel and 2-Section
Boom
Ref. C
2791199
Wisconsin with Steering Wheel, Oil Cooler and 2-
Section Boom
Ref. C
2791203
Wisconsin with Steering Wheel, Oil Cooler and 3-
Section Boom
Ref. C
2791202
Wisconsin with Steering Wheel and 3-Section
Boom
Ref. C
GAS ENGINE WITH VICKERS VALVES AND
HYDRAULIC CONTROLS
Ref.
2791450 Ford Engine (Prior to March 1995) Ref. 8
2792200 Ford Engine (March 1995 to Present) Ref. 2
2791445 Wisconsin Engine Ref. 8
2791754 Wisconsin Engine (Dow Chemical) Ref. 7
