2-194 3120241
SECTION 2 TURNTABLE S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
212 Not Used
213 4751400 Flatwasher 1/4" 3
214 0641610 Bolt 3/8"-16NC x 1 1/4" 4
215 4751600 Flatwasher 3/8" 8
216 4761600 Lockwasher 3/8" 4
217 3311601 Nut 3/8"-16NC 4
218 4841978 Weldment, Box Mounting 1
219 4640558 Valve, Ground Control 1
7009353 Cartridge (With Knob) 6
7009354 Cartridge (Without Knob) 2
220 0901518 Bracket, Valve Mounting 1
221 0641508 Bolt 5/16"-18NC x 1" 2
222 4761500 Lockwasher 5/16" 6
223 3311501 Nut 5/16"-18NC 6
224 0641538 Bolt 5/16"-18NC x 4 3/4" 4
225 4751500 Flatwasher 5/16" 4
226 3251869 Decal, Lift Down 1
227 3251868 Decal, Lift Up 1
228 3251866 Decal, Telescope In 1
229 3251867 Decal, Telescope Out 1
230 3251864 Decal, Swing Left 1
231 3251865 Decal, Swing Right 1
GROUND CONTROL INSTALLATIONS (VARIABLE
PARTS)
Ref.
0239273 DEUTZ F2L511/F3L912 Ref. D
0251644 DEUTZ F3L1011 Ref. F
0239272 FORD (Prior to S/N 36897) Ref. G
0256662 FORD - LRG (S/N 36897 to Present) Ref.
0239271 WISCONSIN Ref. F
251 Gauge, Voltmeter Options: 1
2420091 Deutz F2L511/F3L912
2420129 Deutz F3L1011
2420091 Ford/Ford - LRG
2420091 Wisconsin
252 Gauge, Oil Pressure Options: 1
2420030 Deutz F2L511/F3L912
2420111 Deutz F3L1011
2420035 Ford/Ford - LRG
Not Required Wisconsin
253 Gauge, Water Temperature Options: 1
Not Required Deutz F2L511/F3L912
2420125 Deutz F3L1011
2420019 Ford/Ford - LRG
Not Required Wisconsin
FIGURE 2-48. GROUND CONTROL COMPONENTS INSTALLATION (MACHINES WITH HYDRAULIC
CONTROLS) (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
