3120241 1-13
S
E
C
T
I
O
N
1
F
R
A
M
E
SECTION 1 FRAME
FIGURE 1-3. FRAME AND STEERING INSTALLATION - 4WD
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
FRAME WELDMENT OPTIONS Ref.
Fixed Axle Frames:
2360233 Mid 1984 to January 1992
2360350 January 1992 to Present
Oscillating Axle Frames:
2360231 40H Built Mid 1984 to March 1985
2360236 40H Built March 1985 to January 1992
2360348 40H Built January 1992 to Present
2360307 40H+6 and 46H
0236717 OPTION OSCILLATING FRONT AXLE INSTALLATION -
STANDARD CAPACITY BUILT PRIOR TO APRIL 1993 Ref. E
0253091 OPTIONAL OSCILLATING FRONT AXLE INSTALLA-
TION - STANDARD CAPACITY BUILT APRIL 1993 TO
PRESENT Ref. 5
0253093 OPTION OSCILLATING FRONT AXLE INSTALLATION -
800 LBS UNRESTRICTED CAPACITY Ref. 3
1 Axle Lockout Cylinder Assembly Options (See Section 5
for Breakdown) 2
1681557 Cylinder (Prior to March 1985)
1681571 Cylinder (March 1985 to April 1993)
1682727 Cylinder (April 1993 to Present)
1682727 Cylinder (800Lbs. Unrestric Capacity)
2 Front Axle Weldment Options: 1
4842153 Axle (Prior to April 1993)
4842153 Axle (April 1993 to Present)
4843698 Axle (800Lbs. Unrestricted Capacity)
2A Bushing (Axle Pivot) Options: 2
0961003 Bushing (Prior to February 1994)
0961771 Bushing (February 1994 to Present)
0961003 Bushing (800Lbs. Unrestric Capacity)
2B Bushing (Kingpin Pivot) Options: 4
0961029 Bushing (Prior to February 1994)
0961073 Bushing (February 1994 to Present)
0961029 Bushing (800Lbs. Unrestric Capacity)
3 2540002 Grommet 11 in.
4 2160002 Fitting, Grease - Straight A/R
5 Clevis Pin (Top) Options: 2
3421622 Pin (Prior to March 1985)
3421227 Pin (March 1985 to Present)
6 4712600 Flatwasher 1" 4
7 3450606 Pin, Cotter 3/8" x 1 1/2" 4
8 0641636 Bolt 3/8"-16NC x 4 1/2" 1
9 4751600 Flatwasher 3/8" 3
10 3311605 Locknut 3/8"-16NC 1
11 2160003
Fitting, Grease - 45
° A/R
12 3451214 Pin, Cotter 3/8" x 3 1/2" 1
13 3421128 Pin, Front Axle 1
