2-124 3120241
SECTION 2 TURNTABLE S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
25 Bracket (Radiator) Option: 2
0901180 Prior to March 1990
0901651 March 1990 to March 1995
26 3940804 Screw, Self-Tapping #8 x 1/2" 12
27 4750800 Flatwasher #8 12
28 3620026 Radiator Assembly 1
29 2060014 Fan 1
30 Shroud Options: 1
2680333 Prior to May 1990
2680386 May 1990 to March 1995
31 2720232 Hose, Radiator (Bottom) 1
32 1320014 Clamp, Hose 3
33 Radiator Hose (Top) Options: 1
2720233 Prior to June 1987
2720254 June 1987 to March 1995
34 1320031 Clamp, Hose 1
35 4360037 Switch, Oil Pressure 1
36 2420024 Sender, Temperature 1
37 0100020 Sealant, Pipe (Not Shown) A/R
38 2420033 Sender, Oil Pressure 1
39 2180360 Fitting, Tee 1
40 2220273 Fitting, Reducer 1
41 Auxiliary Pump Assembly Options: 1
Note: When replacing complete assy recommend P/N
3600071.
3600051 Pump Assembly (Prior to October 1984)
7004415 Pump Only 1
7004408 Coupling Only 1
3600115 Pump Assembly (October 1984 to June 1987)
7004412 Coupling Only 1
7013755 Motor, Replacement 1
3600052 Pump Assembly (June 1987 to October 1990)
7004416 Pump Only 1
7004412 Coupling Only 1
7000483 Motor, Replacement - Includes Coupling 1
3600071 Pump Assembly (October 1990 to March 1995)
7004247 Pump Only 1
7004249 Coupling Only 1
7004248 Motor, Replacement 1
7004436 Motor with Bracket 1
7012576 Bracket Only 1
42 to 46 Not Used
47 4751600 Flatwasher 3/8" 11
48 0641610 Bolt 3/8"-16NC x 1 1/4" 6
49 3311601 Nut 3/8"-16NC 6
50 3250914 Decal - Caution 2
51 Cable (Battery) Options: 1
1060045 Prior to August 1992
1060093 August 1992 to March 1995
FIGURE 2-31. FORD LSG 423 ENGINE INSTALLATION (WITH DISTRIBUTOR) (PRIOR TO MARCH
1995) (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
