JLG 40H Parts Manual - Manual (Page 329)

3120241 4-41
S
E
C
T
I
O
N
4
P
L
A
T
F
O
R
M
S
SECTION 4 PLATFORMS
FIGURE 4-9. CAPACITY INDICATOR INSTALLATION (OPTIONAL).
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
Note: Use 1-207 for machines with standard con-
trols built prior to September 1991 and all machines
with hydraulic controls. Use 301-403 for machines
with standard controls built September 1991 to
April 1995. Use 501-652 for machines with standard
controls built April 1995 to present
Ref.
GAGE INSTALLATIONS (STANDARD PARTS) (SEE
NOTE FOR USAGE)
Ref.
1 4220044 Stop, Throttle 2
2 4160058 Spring, Torsion 1
3 3900111 Screw, Shoulder 3/8"-16NC x 1 3/4" 1
0100011 Loctite #242 A/R
GAGE INSTALLATIONS (VARIABLE PARTS) (SEE
NOTE FOR USAGE)
Ref.
51 Cable Options: 1
1060168 Cable (40H with Racine and Bertea Valves)
1060168
Cable (40H/40H+6/46H with Vickers Valves, with
Prop Tele and with Standard Platform)
1060369
Cable (40H/40H+6/46H with Vickers Valves, without
Prop Tele and with Standard Platforms)
1060417
Cable (40H with Vickers Valves and Low Mount Plat-
forms)
1060369
Cable (40H+6/46H without Prop Tele and with Low
Mount Platform)
1060168
Cable (40H+6/46H with Prop Tele and with Low
Mount Platform)
52
Capacity Indicator Gage Options (See Items 101-151
for Breakdown)
1
2420055 Gage (Domestic/Standard)
2420050 Gage (CSA/2:1 Stability)
CAPACITY INDICATOR GAGE ASSEMBLIES (VARI-
ABLE PARTS)
Ref.
2420055 DOMESTIC/ STANDARD Ref.
2420050 CSA/2:1 STABILITY Ref.
101 2420057 Housing 1
102 0440042 Bearing, Ball 2
103 4561774 Tube, Spacer 1
104 Nameplate - Capacity Options: 1
1700503 Domestic/Standard
1700502 CSA/2:1 Stability
