3120241 3-5
S
E
C
T
I
O
N
3
B
O
O
M
SECTION 3 BOOM
Standard 40H with Hydraulic Controls
0800378 Prior to February 1990
0800647 February 1990 to Present
0801099 800 LBS. Capacity with Hydraulic Controls
0800378 46H/40H+6 with Standard Controls
102 0960957 Bushing, Bronze 2
103 Fly Weldment Options: 1
Standard 40H with Standard Controls
0800377 Prior to June 1985
0800415 June 1985 to Present
0800415 800 LBS. Capacity with Standard Controls
0800576 Standard 40H with Hydraulic Controls
0800576 800 LBS. Capacity with Hydraulic Controls
0800469 46H/40H+6 with Standard Controls
104 3421069
Pin (Slave Cylinder Attach) with Standard/Hydraulic
Controls
1
See Figure 3-5 46H/40H+6 with Standard Controls
105 4740006 Washer, Hardened with Standard/Hydraulic Controls 1
See Figure 3-5 46H/40H+6 with Standard Controls
106 Tube Options: 1
Standard 40H with Standard Controls
4562557 Prior to May 1985
1180152 May 1985 to Present
1180152 800 LBS. Capacity with Standard Controls
Standard 40H with Hydraulic Controls
1180183 Prior to July 1990
1180263 July 1990 to Present
1180263 800 LBS. Capacity with Hydraulic Controls
1180152 46H/40H+6 with Standard Controls
107 1180103 Carrier 1
7006132 One Foot Section (2A Version through 1989) A/R
7006140 One Foot Section (2CP Version 1990 to Present) A/R
7006121 Mounting Feet (2A Version through 1989) A/R
7006149 Mounting Feet (2CP Version 1990 to Present) A/R
7006137
Pin Kit (Includes 1 pin, 1 Retaining Ring & 4 Wash-
ers) (2A Version through 1989)
A/R
7006152
Pin Kit (Includes 1 pin, 1 Retaining Ring & 4 Wash-
ers) (2CP 1990 to Present)
A/R
Note: 2A version powertrack has a link height
of 1 3/4” and the pin are 2 1/2” apart (center to
center) 2CP version powertrack has a link
height of 2” and the pin are 3” apart (center to
center)
1180180
Carrier (800 LBS. Capacity with Hydraulic Controls
Only)
1
7006190 One Foot Section A/R
7006143 Mounting Feet A/R
7006138
Pin Kit (Includes 1 link pin, 1 retaining ring & 4
washers of various thicknesses)
A/R
FIGURE 3-1. 2 SECTION BOOM ASSEMBLIES (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
