SECTION 2 TURNTABLE
FIGURE 2-48. GROUND CONTROL COMPONENTS INSTALLATION (MACHINES WITH HYDRAULIC
CONTROLS)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
GROUND CONTROL BOX ASSEMBLY (STANDARD
PARTS)
Ref.
1
0860547
Box
1
2
Not Used
3
2600093
Hinge
1
4
3911006
Screw, Round Head #10-24NC x 3/8"
A/R
5
4761000
Lockwasher #10
A/R
6
3311001
Nut #10-24NC
A/R
7
3911008
Screw, Round Head #10-24NC x 1/2"
12
8
3740049
Relay - SPDT
A/R
9
4750600
Flatwasher #6
2
10
3740016
Relay - 3PDT
1
11
4120002
Socket, Relay
1
12
3910606
Screw, Round Head #6-32NC x 3/8"
2
13
3910610
Screw, Round Head #6-32NC x 5/8"
A/R
14
4760600
Lockwasher #6
A/R
15
3310601
Nut #6-32NC
A/R
16
0750806
Screw #8 x 3/4"
2
17
3300177
Nut, Tinnerman
2
18
4420037
Strip, Rubber
33 in.
19
0100001
Adhesive (Not Shown)
A/R
20
4460051
Connector, Strain Relief
2
21
3300048
Nut, Conduit
4
22
0960238
Bushing
4
23
4360186
Breaker, Circuit - 35 Amp
1
24
Not Used
25
4360069
Breaker, Circuit - 10 Amp
2
26
4360003
Switch, Key
1
2860002
Key, Replacement
1
27
Not Used
28
4360199
Switch, Toggle
1
29
4360274
Switch, Push Button
1
30
Not Used
31
Not Used
32
4460071
Connector, Strain Relief
2
33
3911016
Screw, Round Head #10-24NC x 1"
3
34
3790012
O-Ring
6
35
Not Used
36
3640555
Rail
6 in.
37
4460299
Stop, Terminal
1
38
4460298
Strip, Terminal
11
39
4460301
Marker, Terminal
1
40
4460308
Bar, Buss (2 Position)
1
41
4460305
Screw, Terminal
7
42
4460306
Washer, Terminal
7
43
4460307
Sleeve, Terminal
7
44
4460311
Bar, Buss (5 Position)
1
