SECTION 2 TURNTABLE
FIGURE 2-31. FORD LSG 423 ENGINE INSTALLATION (WITH DISTRIBUTOR) (PRIOR TO MARCH
1995)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
0236344
ENGINE ASSEMBLY - STANDARD GAS WITH GEAR
PUMP AND ADECO THROTTLE (PRIOR TO JUNE
1987)
Ref. L
0238345
ENGINE ASSEMBLY - STANDARD GAS WITH GEAR
PUMP AND PRECISION GOVERNOR (JUNE 1987 TO
FEBRUARY 1995)
Ref. L
0237523
ENGINE ASSEMBLY - STANDARD GAS WITH PISTON
PUMP (PRIOR TO MARCH 1995)
Ref. A
0236543
ENGINE ASSEMBLY - DUAL FUEL WITH GEAR PUMP
AND ADECO THROTTLE (PRIOR TO JUNE 1987)
Ref. J
0238347
ENGINE ASSEMBLY - DUAL FUEL WITH GEAR PUMP
AND PRECISION GOVERNOR (JUNE 1987 TO MARCH
1995)
Ref. O
1 Engine Options: 1
2000073 Prior to August 1984
2000086 August 1984 to June 1987
2000088 June 1987 to March 1995
2 Pump Assembly (Main) Options: 1
3600072
Gear Pump Assembly (Prior to June 1987) (See Fig-
ure 2-41 for Breakdown)
3600139
Gear Pump Assembly (June 1987 to February 1995)
(See Figure 2-42 for Breakdown)
3600126
Piston Pump Assembly (See Figure 2-44 for Break-
down)
3 Not Used
4 Not Used
5 0641812 Bolt 1/2"-13NC x 1 1/2" 2
6 4761800 Lockwasher 1/2" 2
7 Not Used
8 4761600 Lockwasher 1/2" A/R
9 0641608 Bolt 3/8"-16NC x 1" 2
10 Plate, Mounting (Engine) Options: 1
3509613 Prior to April 1986
3509816 April 1986 to March 1995
11 3200200 Bracket, Support - Engine (Front) 1
12 0701014 Bolt, Metric 10mm x 30mm 3
13 0701015 Bolt, Metric 10mm x 35mm 1
14 4832000 Lockwasher 10mm 4
15 4740275 Spacer 1
16 0630360 Bolt, Carriage 2
17 4761500 Lockwasher 5/16" 2
18 4751500 Flatwasher 5/16" 6
19 3200062 Mount, Motor 4
20 0960991 Bushing 1
21 4751800 Flatwasher 1/2" 3
22 3311805 Locknut 1/2"-13NC 3
23 0641828 Bolt 1/2"-13NC x 3 1/2" 1
24 0641820 Bolt 1/2"-13NC x 2 1/2" 2
