SECTION 5 CYLINDER
FIGURE 5-1. AXLE LOCKOUT CYLINDER ASSEMBLY - 4WD/2WS (PRIOR TO SEPTEMBER 1992)
(USE WITH OPTIONAL OSCILLATING AXLE)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
Note: This seal arrangement used on 2WD
machines built prior to March 1985 and 4WD
machines built prior to april 1993.
Ref.
1681523
LOCKOUT CYLINDER ASSEMBLY (2WD BUILT PRIOR
TO MID 1984)
Ref. B
1681536
LOCKOUT CYLINDER ASSEMBLY (2WD BUILT MID
1984 TO MARCH 1985)
Ref. B
1681556
LOCKOUT CYLINDER ASSEMBLY (4WD -BUILT
PRIOR TO MARCH 1985)
Ref. A
1681571
LOCKOUT CYLINDER ASSEMBLY (4WD - BUILT
MARCH 1985 TO APRIL 1993)
Ref. G
1 Barrel Options: 1
1680726 2WD Built Prior to Mid 1984
1680741 2WD Built Mid 1984 to March 1985
1680760 4WD Built Prior to March 1985
1681458 4WD Built March 1985 to April 1993
2 Options: A/R
4640273 Bleeder (Machines Built Prior to March 1985) 4
3900175
Setscrew 1/4"-28NC x 3/4" (Machines Built March
1985 to April 1993)
4
3960416 Seal, Thread A/R
3321401 Nut 1/4"-28NC 4
3 Nut Options: 1
1120108 2WD Built Prior to Mid 1984
3300187 2WD Built Mid 1984 to March 1985
3300273 4WD Built Prior to April 1993
4 Setscrew Options: A/R
3900141 Machines Built Prior to March 1985 3
3900170 Machines Built March 1985 to April 1993 1
5 Kit Seal, Tee 1
6 Kit O-Ring 1
7 Kit Ring, Wear 1
8 Piston Options: 1
3480134 2WD Built Prior to Mid 1984
3480120 2WD Built Mid 1984 to March 1985
3480107 4WD Built Prior to March 1985
3480134 4WD Built March 1985 to April 1993
9 Spacer Options: 1
4562595 2WD Built Prior to Mid 1984
4562687 2WD Built Mid 1984 to March 1985
4562859 4WD Built Prior to April 1993
10 Kit O-Ring 1
Kit Ring, Backup (4WD Built Prior to March 1985 Only) 1
11 Kit Ring, Wear 1
