JLG 40H Parts Manual - Manual (Page 249)

3120241 2-185
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
SECTION 2 TURNTABLE
FIGURE 2-47. GROUND CONTROL COMPONENTS INSTALLATION (VICKERS VALVE MACHINES
WITH STANDARD CONTROLS)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
0238054
GROUND CONTROLS INSTALLATION - DEUTZ
F2L511 AND F3L912
Ref. E
0251643
GROUND CONTROLS INSTALLATION - DEUTZ
F3L1011
Ref. C
0238053 GROUND CONTROLS INSTALLATION - FORD Ref. C
0238132 GROUND CONTROLS INSTALLATION - WISCONSIN Ref. D
GROUND CONTROL BOX AND HARNESS ASSEM-
BLY OPTIONS (INCLUDES ITEMS 80-83):
Ref.
0860548
Deutz F2L511/F3L912, Ford and Wisconsin (June
1987 to May 1994)
0860909
Deutz F2L511/F3L912, Ford and Wisconsin (May
1994 to Present)
0860709 Deutz F3L1011 (Prior to May 1994)
0860932 Deutz F3L1011 (May 1994 to Present)
1 0641406 Bolt 1/4"-20NC x 3/4" 3
2 4751400 Flatwasher 1/4" 3
3 4761400 Lockwasher 1/4" 3
4 3311401 Nut 14"-20NC 3
5 4841978 Bracket, Box Mounting 1
6 0641610 Bolt 3/8"-16NC x 1 1/4" 4
7 4751600 Flatwasher 3/8" 4
8 4761600 Lockwasher 3/8" 4
9 3311601 Nut 3/8"-16NC 4
10 3380309 Panel, Gauge (Ford and Deutz F3L1011) 1
0901212 Panel, Gauge (Deutz F2L511) 1
0901212 Panel, Gauge (Deutz F3L912) (Prior to S/N 30866) 1
3380309 Panel, Gauge (Deutz F3L912) (S/N 30866 to Present) 1
0901213 Panel, Gauge (Wisconsin) 1
11 0641406 Bolt 1/4"-20NC x 3/4" 3
12 4761400 Lockwasher 1/4" 3
13 3311401 Nut 1/4"-20NC 3
14 2420091 Gauge, Voltmeter (All Except Deutz F3L1011) 1
2420129 Gauge, Voltmeter (Deutz F3L1011 Only) 1
15 2420035 Gauge, Oil Pressure (Ford) 1
2420030 Gauge, Oil Pressure (Deutz F2L511/F3L912) 1
2420111 Gauge, Oil Pressure (Deutz F3L1011) 1
2220574 Fitting (Deutz) - (Not Shown) 1
2220295 Fitting, Coupling (Deutz) - (Not Shown) 1
0100020 Sealant, Pipe A/R
16 2420019 Gauge, Water Temperature (Ford Only) 1
2420125 Gauge, Oil Temperature (Deutz F3L1011 Only) 1
17 2420009 Gauge, Hourmeter 1
