JLG 40H Parts Manual - Manual (Page 112)

2-48 3120241
SECTION 2 TURNTABLE S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
43 7004821 Guide Tube Assembly (1 Per Solenoid Assembly) A/R
44 7002345 Cone, Female (1 Per Solenoid Assembly) A/R
Kit O-Ring (1 Per Solenoid Assembly) A/R
Kit O-Ring (1 Per Solenoid Assembly) A/R
45 7002346 Pin, Push (1 Per Solenoid Assembly) A/R
46 7002344 Plunger (1 Per Solenoid Assembly) A/R
47 7000470 Tube, Guide (1 Per Solenoid Assembly) A/R
48 7002341 Pin, Actuator (1 Per Solenoid Assembly) A/R
Kit Ring, Quad (1 Per Solenoid Assembly) A/R
49 7002340
Guide, External Push Pin (1 Per Solenoid Assem-
bly
A/R
Kit O-Ring (1 Per Solenoid Assembly) A/R
50 7002333 Sleeve, Inner Flux (1 Per Solenoid Assembly) A/R
51 7002334 Spring (1 Per Solenoid Assembly) A/R
52 7002336 Sleeve, Outer Flux (1 Per Solenoid Assembly) A/R
53 7000418 Coil (1 Per Solenoid Assembly) A/R
54 7002335 Case, Solenoid (1 Per Solenoid Assembly) A/R
55 7002338 Plate, End (1 Per Solenoid Assembly) A/R
56 7002339 Screw (4 Per Solenoid Assembly) A/R
WORKING SECTION (VARIABLE PARTS) Ref.
Note: Complete Sections listed below include items 40-56
and relief valve assembly when equipped
101 Section #1 Options: 1
7002317 Rotate Section (4640247 Valves)
7002315 Steer/Tele Section (4640571 and 4640246 Valves)
102 Section #2 Options: 1
7002315 Steer/Tele Section (4640246 Valves)
7011182 Level Section (4640571 and 4640247 Valves)
103 Section #3 Options: 1
Not Required (4640571 Valves)
7002315 Steer/Tele Section (4640246 Valves)
7011182 Level Section (4640247 Valves)
104 Section #4 Options: 1
Not Required (All except 4640247 Valve)
7002315 Steer/Tele Section (4640247 Valve Only)
— — — — — — — — — —
105 Relief Valve Options: A/R
7000468
Crossover Relief Valve Assembly - 7002315 Steer/
Tele Sections) (Due to various suppliers - internal
components are no longer field serviceable)
7011183
Relief Valve Assembly - 7011182 Level Sections
(Due to various suppliers - internal components are
no longer field serviceable)
A/R
— — — — — — — — — —
7000414 Seal Kit - Working Section 4
7000413 Seal Kit - Dump Section 1
FIGURE 2-12. CONTROL VALVE ASSEMBLY - BANG-BANG WITH DUMP SECTION (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
