3120241 5-1
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
SECTION 5 CYLINDER
TABLE OF CONTENTS
FIGURE DESCRIPTION PAGE
5-1 AXLE LOCKOUT CYLINDER ASSEMBLY - 4WD/2WS (PRIOR TO SEPTEMBER 1992)
(USE WITH OPTIONAL OSCILLATING AXLE) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
5-2 AXLE LOCKOUT CYLINDER ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
5-3 LIFT CYLINDER ASSEMBLY - BOOM (PRIOR TO APRIL 1993) . . . . . . . . . . . . . . . . . . . . . . . 5-10
5-4 LIFT CYLINDER ASSEMBLY - BOOM (APRIL 1993 TO PRESENT). . . . . . . . . . . . . . . . . . . . . 5-12
5-5 LIFT CYLINDER ASSEMBLY - EXTEND-A-REACH (40H+6 ONLY) . . . . . . . . . . . . . . . . . . . . . 5-14
5-6 MASTER CYLINDER ASSEMBLIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-16
5-7 SLAVE LEVEL CYLINDER ASSEMBLIES (BUILT PRIOR TO JANUARY 1987) . . . . . . . . . . . . 5-18
5-8 SLAVE LEVEL CYLINDER ASSEMBLIES (JANUARY 1987 TO APRIL 1992). . . . . . . . . . . . . . 5-20
5-9 SLAVE LEVEL CYLINDER ASSEMBLIES (APRIL 1992 TO PRESENT) . . . . . . . . . . . . . . . . . . 5-22
5-10 SLAVE LEVEL CYLINDER ASSEMBLIES (MODEL 40H+6 EXTEND-A-REACH)
(PRIOR TO S/N 47925) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-24
5-11 SLAVE LEVEL CYLINDER ASSEMBLIES (MODEL 40H+6 EXTEND-A-REACH)
(S/N 47925 TO PRESENT) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-26
5-12 STEER CYLINDER ASSEMBLY - 2WD (PRIOR TO MID 1984). . . . . . . . . . . . . . . . . . . . . . . . . 5-28
5-13 STEER CYLINDER ASSEMBLY - 2WD (MID 1984 TO PRESENT) . . . . . . . . . . . . . . . . . . . . . . 5-30
5-14 STEER CYLINDER ASSEMBLY - 4WD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-32
5-15 TELESCOPE CYLINDER ASSEMBLY (2-SECTION) (PRIOR TO JULY 1985) . . . . . . . . . . . . . 5-34
5-16 TELESCOPE CYLINDER ASSEMBLY (2-SECTION) (JULY 1985 TO PRESENT) . . . . . . . . . . 5-36
5-17 TELESCOPE CYLINDER ASSEMBLY (3-SECTION). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-38
5-18 CYLINDER BELLOWS INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-40
