14
Excella E-24/24R Incubator Shakers  M1352-0050 Operating Manual
Figure 3b: Clamp Fastener


NOTE:
The upper girdle secures the flask within the clamp, and the bottom girdle
keeps the flask from spinning.
New Brunswick flask clamps are used on a variety of shaker platforms. Flat head
screws of different lengths and thread pitch are used to secure the clamp. With
reference to Figure 3b above, select the appropriate screws and set the others aside.

NOTE:
One-liter and larger flask clamps are fastened with 5 screws.
4.3 Electrical Connections
CAUTION!
Before making electrical connections, be sure to check the following:
1. If you have not already done so, check that the voltage and frequency of your unit are
compatible with your electric supply.
2. Remove the caution label from the rear of the unit.
3. Set the circuit breaker on the right side of the unit to the OFF position.
ONLY THEN:
4. Plug the power cord into a grounded electrical outlet.
CAUTION!
A grounded electrical outlet is necessary for the safe operation of this
instrument.
