PARTS PARTS PARTS PARTS PARTS
LISTING LISTING LISTING LISTING LISTING
ADVANCE ADAPTERS INC. P/N: RANGER OD
P.O. Box 247, 4320 Aerotech Center Way
Paso Robles, CA 93447
PAGE 7 OF 11
Telephone: (800) 350-2223 Fax: (805) 238-4201 Page Rev. Date: 06-19-12
PART # DESCRIPTION Item#
761074 SHIFT FORK (New Style) 1
723705 3/8"-24 NF NUT 5
761028 SIDE COVER GASKET 7
761029 SPRING (Shift Fork) 8
761023 3/8" STEEL BALL (Ford & Cover) 9
761301 NEW STYLE RANGER III (5/88) 10
761307 SIDE COVER GASKET-RAN III 11
761302 SIDE COVER HANDLE CAP 12
761045 "O"-RING SEAL (Shift Rail Seal) 13
761124-A FILL PLUG 15
723110 5/16"-18 x .75 S.H.C.S. 16
761044 SHIFT RAIL 17
723752 SET SCREW FOR SHIFT RAIL 18
761309 ZERK FITTING 20
761033 CHEVY & GM 5.125" DIA. 21
761037 4SP TOYOTA L/C 5.038" DIA. 21
761034 FORD 4.848" DIA. 21
761026 REAR PLATE GASKET 22
761005C CHEVY & GM CASE 23
761005F FORD CASE 23
761024 FRONT COVER GASKET 24
761064 FRT. LOW. BRG. COV. PLATE 25
720015 10"-24 x .375" LG. F.H.C.S. 26
761098 SEAL-C/R # 12363 27
761027 GASKET 28
761015 CHEVY & GM 4.686" 29
761016 CHEVY & GM 5.125" 29
761019 FORD 4.848" 29
723113 S.H.C.S. 5/16"-18 x 3/4" 30
723119 5/16"-18 NC x 1.25" H.H.C.S. 31
*761065 (discon't) DRIVE SLEEVE BUSHING
761096 INPUT SHAFT BEARING (7/88) 32
(BA-2212-ZOH-MFG-1K0)
*Note: Units having a bushing will require the input shaft to be
I.D. ground to fit the new roller bearing.
761053 CHEVY & GM SPLINE 1-1/8" 10 33
761054 FORD SPL. 1-1/16" 10 x 6-1/2" 33
761069 OIL SLINGER - BW #T90A-136A 34
761093 BEARING FOR INPUT SHAFT 35
(BCA # N1308LOB)
PART # DESCRIPTION Item#
761083 SNAP RING 36
761081 SNAP RING 37
761092 BRG. FOR LOW. CLUSTER GEAR 38
(BCA # 306L)
761102 27% O.D. CLUSTER GEAR 39
761091 FRT. BRG. FOR CLUSTER GEAR 40
(BCA # M-1305GTV)
761085 SNAP RING 41
761090 REAR BRG. FOR DRIVE SLEEVE 42
(BCA # 211SSL)
761103 STEEL BEARING RETAINER 43
761001 CHEVY/GM DRIVE SLEEVE 44
1-1/8" 10 (27% O.D. - 17% U.D.)
761002 FORD DRIVE SLEEVE 44
(27% O.D. - 17% U.D.)
761052 27% O.D. GEARS - 23 TEETH 45
761070 COMPLETE SYNCHRO ASSY. 46
300372 SYNCHRO DOGS-HOLLOW (Ea.)
300370 BRASS SYNCHRO RING (Ea.)
300371 SLIDER RING
300373 SYNC. DOG WIRE SPRINGS (Ea.)
761070E SYNCHRO HUB
761084 SNAP RING 47
761124 INSPECTION COVER 48
761105 HANDLE 51
761073 SHIFT KNOB 52
723721 3/8"-16 NC x 1" LG. S.H.C.S. 64
723704 7/8" LOCK WASHER 65
723139 5/16"-18 NC x 1.50" LG. S.H.C.S. 67
761306 PIN BAR ASSEMBLY 68
761304 BALL DETENT BAR 69
761305 HANDLE MOUNTING SHAFT 70
761313 HEX NUT 72
761314 COTTER PIN
761000 GASKET AND SEAL SET (Early)
761000NS GASKET AND SEAL SET (Ranger III)
