ADVANCE ADAPTERS INC. P/N: 715596
P.O. Box 247, 4320 Aerotech Center Way New Item: (11/10)
Paso Robles, CA 93447 PAGE 1 of 7
Telephone: (800) 350-2223 Fax: (805) 238-4201 Page Rev. Date: 07-26-11
SPECIAL NOTE: The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the
components will void any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your
conversion, we strongly recommend that you contact our sales department for more information. This instruction sheet is only to be used for the assembly of
Advance Adapter components. We recommend that a service manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other
related equipment. These manuals are normally available at automotive dealerships and parts stores.
KIT CONSISTS OF:
No. Qty Part No. Description
JK CABLE SHIFT LINKAGE UPGRADE KIT
1. 22 303311 HEAT SHIELD-FIREPROOF SLEEVE 1/2"
2. 2 303313 HEIM JOINT - FEMALE 1/4"-28
3. 2 340615 BOLT - 1/4"-20 X 5/8" B.H.C.S
4. 1 42R725 SHIFTER CABLE - 2" TRAVEL
5. 2 42R735 BOLT 1/4"-20 X 1" H.H.C.S. GRD 8
6. 1 42R740 BOLT 8mm X 1.25 X 14mm H.H.C.S.
7. 1 715596A PIVOT ASSEMBLY
8. 1 715596A1 PIVOT BLOCK
9. 1 715596B BRACKET-CABLE MOUNT
10. 1 715596C LEVER - TRANSFER CASE
11. 1 715596E SPACER - TRANSFER CASE LEVER
12. 5 722514 NYLON LOCKNUT 1/4"-20
13. 1 722523 1/4" USS FLAT WASHER PLTD.
14. 1 722530 1/4" X 20" X 3/4" S.H.C.S.
15. 2 722532 1/4"-20 X 3/4" H.H.C.S. GRD 5
16. 1 722543 1/4" X 20" X 1-1/2" S.H.C.S.
17. 2 726207 5/8" FLAT WASHER SAE OD
18. 1 29-2004 YOKE NUT
Notes:
The stock Jeep linkage uses plastic heim joints and a light duty shifter cable. The shifting of this transfer case and
stock linkage puts wear and tear on these shifter components and eventually will wear them out. Our new cable
upgrade keeps all the stock interior look and provides a positive shifting assembly that will provide a great addition
to your Jeep JK.
This kit replaces the stock Jeep cable assembly with a heavy duty push/pull cable equipped with quality steel heim
joints providing you a reliable linkage assembly.
Assembly video of this product found at ( http://www.youtube.com/watch?v=5OrMzFQ2ssg ).
