alTeRnaTe seTUP MeTHod

Note: Your Router may have ports in different locations than depicted in the illustration above�

1�6 Before plugging the power

cord into the Router, plug

the cord into the wall,

then plug the cord into the

Router’s power jack�

LAN

WAN

1.4

1.6b

1.5

1.1

1.6 a

1.2

1.3

1�8 Verify that your computer

is connected properly to

the Router by checking

the lights labeled “1–4”�

The light that corresponds

to the numbered port

connected to your computer

should be ON if your

computer is connected

properly� If it is not, recheck

your connections�

1�7 Verify that your modem is

connected to the Router

by checking the lights on

the front of the Router� The

green light labeled “Modem”

should be ON if your modem

is connected correctly to the

Router� If it is not, recheck

your connections�
