6.
Emergency Battery Isolating Plug.
Disconnecting this plug will isolate the batteries from the powerpack
and operating circuits.
Before operating this machine, it is important that both the
Operator and another responsible person on site, is aware of the
position and function of the following:
A) Emergency Stop Buttons.
B) Emergency Lowering Buttons.
C) Emergency Slew Drive Shaft.
D) Battery Isolating Plug.
EMERGENCY CONTROLS
