24
TL49J
513868-000
4. Emergency Procedure, Manual Raising of Outriggers.
In the event of power failure, the outriggers can be raised to their transport position.
First the hand pump hose fitted to port
HP1, must be redirected from HP1, to port HP2,
and the
blanking plug from HP2 must be replaced into HP1, using a 22mm spanner.
Once connected,
move an Outrigger Control Lever in the required direction of
movement, and operate the hand pump. When the Outrigger starts to raise, continue
depressing the control lever.
Some hydraulic oil will be lost during this procedure. This will still
allow Emergency operations, but will need to be replaced before full
normal use can resumed.
!
5. Cage Overload
In the event of the cage being overloaded, an audible alarm will sound and the cage
controls will cut out.
To
re-start, enough load must be removed from the cage so that the alarm stops
sounding.
In cases where the overload can not be immediatley removed or the cage has fouled,
then the overload override selector switch can be used to move the platform to a safe
position so that the overload can safely removed.
The Key, Motor Run/Deadman and a Control Lever must be operated
at the same time to effect this action
EMERGENCY CONTROLS
