2. Operation & Specifications
2-19
SPECIFICATIONS
MB26
PARAMETER MB26N EU VERSION MB26N US VERSION
Duty Cycle
Platform Size
Maximum Platform Capacity
Indoors
Outdoors
Maximum Chassis Inclination
45%over 8 hour cycle
770mm x 730mm
215kg.
2 People
1 Person
2°
35%over 8 hour cycle
30.5in. x 28.5in.
475lbs.
2 People
2 People
2°
Heights:
Maximum Platform Height
Maximum Working Height
Platform Height at Maximum Outreach
7.75m
9.75m
6.51m
25.45ft.
32.00ft.
21.36ft.
Maximum Working Outreach 3m 10ft.
Stowed Dimensions:
Length
Width
Height
2.800m
1.010m
2.010m
9.2ft.
40in.
6.59ft.
Chassis Ground Clearance
Wheelbase x Wheel Gauge
Rotation
Gross Vehicle Weight
Maximum Drive Speed - Stowed
Maximum Drive Speed - Elevated
Maximum Gradeability
Outside Turning Radius
90mm
1465mm x 890mm
360deg non-continuous
2655kg.
3.13 km/h
0.90km/h
25%
1.93m
3.54in.
4.81ft. x 2.93ft.
360 deg non-continuous
7000lbs.
1.94mph.
0.56mph
25%
6.33ft.
Electrical:
Power Source
System Voltage
Battery Charger
Control System
4 x 6V @ 375Ah Battery
24 Volt DC
24V x 30A, 220V 50Hz AC
Single Joystick, Function
Selector, DC Motor Controller
4 x 6V @ 375Ah Battery
24 Volt DC
24V x 30A, 110V 60Hz AC
Single Joystick, Function
Selector, DC Motor Controller
Hydraulic System:
System Relief Setting
Hydraulic Oil Type
Hydraulic Tank Capacity
Brakes
220bar
ISO VG46
18 litres
Spring applied hydraulically
released
3190psi
ISO VG46
4.7 gallons (U.S.)
Spring applied hydraulically re-
leased
Wheels & Tyres 13.5in x 4.0
solid, Non-Marking
13.5in x 4.0
solid, Non-Marking
Noise Pressure Level 68dB (A) at Control Station 68dB (A) at Control Station
