2. Operation & Specifications
2-8
ITEMS NAMES FUNCTION
4 Steering Switch Turns the wheels left or right.
5 Jib Select Button Pre-selects the Jib function.
6 Mast Select Button Pre-selects the Mast function.
7 Rotate Select Button Per-selects the Mast Rotate function.
8 Drive (Mast Raised)
Pre-selects the drive function with the mast in the raised
position and for high torque. (i.e. slow speed)
9 Drive (Mast Lowered)
Pre-selects the drive function with the mast in the lowered
position. (i.e. maximum speed)
10 Key Switch Activates (ON) and De-actives (OFF) all machine functions.
11 Horn Button Use to warn bystanders or to attract attention.
12 Multi-Function Display Displays the Percentage battery life. (99=Full, 01-Empty)
Table 1: Platform Controls and Indicators
LOWER CONTROL PANEL
ITEMS NAMES FUNCTION
1 Enable Button
This button enables the Rocker Switch, and must be held
down during operation.
2 Rocker Switch Activates the pre-selected operation, in either direction
3 Mast Select Button Pre-selects the Mast function.
4 Jib Select Button Pre-selects the Jib function.
5 Rotate Select Button Per-selects the Mast Rotate function.
6 Emergency Stop
Push this red button at any time to isolate power. T urn
clockwise to reset.
