2. Operation & Specifications
2-18
SPECIFICATIONS
MB20N
PARAMETER MB20N EU VERSION MB20N US VERSION
Duty Cycle
Platform Size
Maximum Platform Capacity
Indoors
Outdoors
Maximum Chassis Inclination
45%over 8 hour cycle
770mm x 730mm
215kg.
2 People
1 Person
2°
35%over 8 hour cycle
30.5in. x 28.5in.
425lbs.
2 People
2 People
2°
Heights:
Maximum Platform Height
Maximum Working Height
Platform Height at Maximum Outreach
6.10m
8.10m
5.04m
20.00ft.
26.50ft.
16.54ft.
Maximum Working Outreach 2.64m 8.66ft
Stowed Dimensions:
Length
Width
Height
2.430m
0.810m
2.013m
7.97ft.
32in.
6.60ft
Chassis Ground Clearance
Wheelbase x Wheel Gauge
Rotation
Gross Vehicle Weight
Maximum Drive Speed - Stowed
Maximum Drive Speed - Elevated
Maximum Gradeability
Outside Turning Radius
90mm
1465mm x 708mm
360deg non-continuous
2590kg.
3.30 km/h
0.90km/h
25%
1.90m
3.54in.
4.81ft. x 2.32ft.
360 deg non-continuous
6640 lbs.
2.05mph.
0.55mph
25%
6.23ft.
Electrical:
Power Source
System Voltage
Battery Charger
Control System
4 x 6V @ 375Ah Battery
24 Volt DC
24V x 30A, 220V 50Hz AC
Single Joystick, Function
Selector, DC Motor Controller
4 x 6V @ 375Ah Battery
24 Volt DC
24V x 30A, 110V 60Hz AC
Single Joystick, Function
Selector, DC Motor Controller
Hydraulic System:
System Relief Setting
Hydraulic Oil Type
Hydraulic Tank Capacity
Brakes
220bar
ISO VG46
20 litres
Spring applied hydraulically
released
3190psi
ISO VG46
5.3 gallons (U.S.)
Spring applied hydraulically
released
Wheel & Tyres 13.5in. x 4.0
solid, Non-Marking
13.5in. x 4.0
solid, Non-Marking
Noise Pressure Level 68dB (A) at Control Station 68dB (A) at Control Station
