Chapter 2 – Specifi cations
Component Identifi cation
Right Side
Front
Rear
Upper Controls
Platform
Power to Platform
Outlet
Riser
Battery Tray
(Both Sides)
Chassis
Hydraulic Fluid Filter
Tie-Down/Lifting Lugs
Front Axle
Drive Control Compartment
Hydraulic Pump • Drive Motors
Battery Charger • Level Sensor
Tie-Down Lugs
Battery Disconnect
Switch
Operator’s
Manual
Front
Platform
Foot Switch
Rear
Lower
Controls
Main Boom
Tip Boom
Jib
Left Side
Tie-Down/Lifting
Lugs
Riser
Boom
Lanyard
Anchors
Power to Platform Inlet
Battery
Charger Plug
Hydraulic
Reservoir
